LFP rechargeable battery

rectangular12 Vfor electric vehicles

Product overview
12.8V LFP backup power supply designed to support 12V low-voltage safety loads in electric vehicles, providing uninterrupted power for braking, automated parking, door unlocking and roadside-assistance calls.

Key features

• Intelligent controls: Four independent outputs (braking, automated parking, door unlocking, roadside assistance) with control strategies adapted to collision events and power failures.
• Long life: Ultra-long lifespan architecture with cycle life ≥ 500,000 cycles to reduce total lifecycle cost and support long-term vehicle requirements.
• Mature CMS platform: High-precision sampling and proprietary algorithms for accurate resistance and capacitance estimation. MOSFET protection replaces traditional fuses for millisecond-level fault response.
• Customizable: Structural design, cell selection, BMS and system-level solutions can be customized to customer requirements.

Technical specifications

• Cell type: LFP
• Rated voltage: 12.8V
• Rated capacity: 5Ah–13Ah
• Operating temperature: -40℃ to 65℃
• Cooling method: Natural cooling
• Discharge current (continuous): 20A
• Communication: LIN / CAN / CAN FD
• OTA: Supported
• Safety level: QM–ASIL D
• IP rating: IP67
• SOC / SOH estimation accuracy: ±5%
• Current sampling accuracy: Range [-200A, 200A], Accuracy ≤ ±1% ± 50mA; Range [-1500A, 1500A], Accuracy ≤ ±2% ± 200mA
• Voltage sampling accuracy: Range [-40, +85]℃, Accuracy ≤ ±5mV; Out of range, Accuracy ≤ ±10mV
• Temperature sampling accuracy: Range [-40℃, +105℃], Accuracy ±2℃
