Mechanical press DA-300

stampingdrawingblanking

Part size: medium to large Application: as a single press in progressive operation or as part of a press line and as a transfer press Description Stamping presses of the DA series are suitable for a wide range of medium sized parts and for blanking as well as drawing With single reduction gear and smaller stroke length, DAH-type presses have the advantage of higher SPM compared to DA-type press. SL2 press guarantees the high productivity and good quality as it is a link motion press which ensures a low down-coming speed and high return speed. Features and Benefits Mid-Size Press model with Powerful force and high accuracy that is suitable for a wide range of jobs from thin plate drawing to thick plate blanking High part quality due to rigid, FEM-optimized press design. Strongly resistant to eccentric loads due to the widely installed SUSPENSION POINT (2-POINTS) and installation of long 6-faced guide The automatic centralized lubrication system increases productivity and availability. Detachable FRAME fastened by TIE ROD (Application of Hydraulic TIE ROD NUT) Low noise level through operating the deceleration gear with high precision in an oil tank room.
