Analysis software Abaqus/Explicit

simulationmodelingpost-processing

Overview
Abaqus/Explicit is an explicit-dynamic finite-element solver designed to simulate short-duration, highly nonlinear transient events such as drop tests, automotive crashes and ballistic impacts. It is also applied to many quasi-static processes where robust handling of nonlinearity, contact and large deformations is required. Abaqus/CAE supports pre- and post-processing for Abaqus/Explicit and the product is engineered for production use with emphasis on usability and efficiency.

Key capabilities

• Explicit-dynamic time integration for short, highly nonlinear events
• Robust handling of complex contact, large deformations and discontinuities
• Hybrid workflows: coupling and switching with Abaqus/Standard (implicit) within analyses
• Integrated pre/post-processing support in Abaqus/CAE for production workflows

Analysis types

• Nonlinear dynamic stress and impact analysis
• Acoustics and vibro-acoustic coupling
• Thermal/structural multiphysics procedures
• Discrete Element Method (DEM) for particle systems
• Coupled Eulerian–Lagrangian (CEL) simulations
• Smooth Particle Hydrodynamics (SPH) for severe fragmentation and fluids

Element types

• Linear solid elements for stress analysis
• Quadratic tetrahedral elements for complex geometries
• Structural elements: shell, beam, truss, membrane
• Elements for coupled thermal/structural simulations
• Special modeling elements for kinematic behaviors, spot welds and adhesive connections

Material models

• Linear and nonlinear elasticity, linear and nonlinear viscoelasticity
• Isotropic and kinematic plasticity models
• Damage and fracture mechanics formulations
• Rate-dependent foam and other high-strain-rate materials
• Equations of state for non-Newtonian fluids and gases

Integration & workflow

• Seamless interoperability with Abaqus/Standard for hybrid implicit/explicit analyses
• Selective use of explicit solver on model subsets to optimize cost and accuracy
• Full pre/post capabilities via Abaqus/CAE for model setup, meshing and results review

Technical specifications

• Solver type: explicit-dynamic finite-element solver
• Primary applications: drop tests, crash simulation, ballistic impact, quasi-static crushing and forming
• Supported advanced methods: DEM, SPH, CEL
• Element & material support: extensive libraries for structural, thermal and special elements and advanced constitutive models
