Wheeled articulated boom lift SJ45/60 AJHE+

self-propelledmobilehybrid

Overview
The SJ45/60 AJHE+ are hybrid-electric rough-terrain articulating boom lifts designed for rental fleets and contractors seeking lower emissions, simplified operation and reduced operating costs. The range emphasizes ease of maintenance and proven Skyjack systems for dependable field performance.

Key product features

• SKYCODED™: Proven, reliable control system with Skyjack color-coded and numbered wiring for simplified troubleshooting and repair.
• ECO: Designed to improve environmental performance and long-term sustainability to support rental and contractor requirements.
• ACCESSORYZERS™: Manufacturer‑approved accessories to enhance machine versatility, protection and productivity.
• EASYDRIVE™: Boom lift controls maintain operator orientation regardless of turret position to reduce operator confusion.
• AXLDRIVE™: Axle‑based drive with operator‑controlled locking differential (rear) and limited‑slip differential (front) for durable, low‑maintenance off‑road capability.
• SKYRISER™: Riser and main pivot travel in a straight vertical line to reduce repositioning when working close to façades.

Product imagery & media
Primary product image for SJ60 AJHE+ and supporting media (product video and familiarization video) are available on the product page to assist inspections and operator familiarization.

Specifications (comparison SJ45 AJHE+ vs SJ60 AJHE+)
Work Height | 51’ (15.54 m) | 66’ (20.11 m)
Platform Height | 45’ (13.72 m) | 60’ (18.29 m)
Up and Over Height | 24’ 5.25” (7.45 m) | 27’ 2” (8.31 m)
Platform Size | 30” x 72” (0.76 x 1.83 m) | 36” x 96” (0.91 x 2.44 m)
Stowed Width | 7’ 6” (2.29 m) | 8’ (2.44 m)
Tailswing | 2’ (0.61 m) | 2’ (0.61 m)
Stowed Height | 6’ 9” (2.06 m) | 8’ 4” (2.54 m)
Transportation Height | 7’ 1” (2.16 m) | 9’ 2” (2.79 m)
Stowed Length | 19’ 8” (6.00 m) | 28’ 2” (8.59 m)
Transportation Length | 15’ 7” (4.75 m) | 21’ 8” (6.60 m)
Ground Clearance | 15.25” (0.39 m) | 13” (0.33 m)
Wheelbase | 6’ 8” (2.03 m) | 8’ (2.44 m)
Rotation | 355° NC | 355° NC
Platform Rotation | 170° | 170°
Jib Length | 4’ 8” (1.40 m) | 5’ (1.52 m)
Jib Range +/- | +70° / -75° | +65° / -60°
Weight | 12,533 lbs (5,685 kg) | 20,177 lbs (9,125 kg)
Gradeability | 45% | 45%
Turning Radius (Inside) | 4’ 11” (1.50 m) | 7’ 3” (2.21 m)
Turning Radius (Outside) | 14’ 3” (4.34 m) | 17’ 5” (5.31 m)
Axle Oscillation | 5” (12.70 cm) | 4” (10.16 cm)
Drive Speed (High speed) | 4.8 km/h | 4.8 km/h
Capacity | 660 lbs (300 kg) | 660 / 1,000 lbs (300 / 454 kg)
Horizontal Reach | 22’ 9” (6.93 m) | 37’ 11” (11.56 m)
Maximum # of Persons | 2 | (not specified)
Wind Rating | 2 @ 28 mph (12.5 m/s) | 2 / 3 @ 28 mph (12.5 m/s)
Tire Type | N/M Solid | N/M Foam‑Filled
Tire Size | 10 x 31 | 14 x 610
Diesel Engine | Kubota D902 | Kubota D902
Hydraulic Reservoir | 24 gal. (91 L) | 30.4 gal (115 L)

Accessories and options (availability by model)
Accessory | SJ45 AJHE+ | SJ60 AJHE+
36” x 72” PLATFORM | not available | available
BIO OIL | available | available
BOOM PIPE RACK | available | available
FLASHING LIGHT | available | available
GLAZIER KIT | available | available
REAR GATE | not available | available
SIDE SPRING HINGED ENTRY GATE | available | not available
TOOL CADDY | available | available
WHITE NOISE ALARM | available | available
ELEVATE | available | available

caractéristiques / spécifications techniques

• Model / series: SJ45/60 AJHE+
• Manufacturer / Brand: Skyjack
• Platform working heights: SJ45 AJHE+ = 45 ft platform (51 ft work height); SJ60 AJHE+ = 60 ft platform (66 ft work height)
• Up-and-over clearance: SJ45 AJHE+ = 24’ 5.25” (7.45 m); SJ60 AJHE+ = 27’ 2” (8.31 m)
• Platform sizes: SJ45 AJHE+ = 30” x 72” (0.76 x 1.83 m); SJ60 AJHE+ = 36” x 96” (0.91 x 2.44 m)
• Stowed dimensions (width x height x length): SJ45 AJHE+ = 7’6” x 6’9” x 19’8” (2.29 m x 2.06 m x 6.00 m); SJ60 AJHE+ = 8’ x 8’4” x 28’2” (2.44 m x 2.54 m x 8.59 m)
• Transportation dimensions (height x length): SJ45 AJHE+ = 7’1” (2.16 m) x 15’7” (4.75 m); SJ60 AJHE+ = 9’2” (2.79 m) x 21’8” (6.60 m)
• Ground clearance: SJ45 AJHE+ = 15.25” (0.39 m); SJ60 AJHE+ = 13” (0.33 m)
• Wheelbase: SJ45 AJHE+ = 6’8” (2.03 m); SJ60 AJHE+ = 8’ (2.44 m)
• Rotation (turret): 355° non-continuous
• Platform rotation: 170°
• Jib length and range: SJ45 AJHE+ jib 4’8” (1.40 m) +70° / -75°; SJ60 AJHE+ jib 5’ (1.52 m) +65° / -60°
• Machine weight: SJ45 AJHE+ = 12,533 lbs (5,685 kg); SJ60 AJHE+ = 20,177 lbs (9,125 kg)
• Gradeability: 45% (both models)
• Turning radii (inside/outside): SJ45 AJHE+ = 4’11” (1.50 m) / 14’3” (4.34 m); SJ60 AJHE+ = 7’3” (2.21 m) / 17’5” (5.31 m)
• Axle oscillation: SJ45 AJHE+ = 5” (12.7 cm); SJ60 AJHE+ = 4” (10.16 cm)
• Drive speed (high): 4.8 km/h (both)
• Rated platform capacity: SJ45 AJHE+ = 660 lbs (300 kg); SJ60 AJHE+ = 660 / 1,000 lbs (300 / 454 kg)
• Horizontal reach: SJ45 AJHE+ = 22’9” (6.93 m); SJ60 AJHE+ = 37’11” (11.56 m)
• Maximum persons: SJ45 AJHE+ = 2; SJ60 AJHE+ unspecified on page
• Wind rating: SJ45 AJHE+ = 2 @ 28 mph (12.5 m/s); SJ60 AJHE+ = 2 / 3 @ 28 mph (12.5 m/s)
• Tires: SJ45 AJHE+ N/M Solid; SJ60 AJHE+ N/M Foam‑Filled (sizes 10 x 31 and 14 x 610 respectively)
• Engine: Kubota D902 (both models)
• Hydraulic reservoir: SJ45 AJHE+ = 24 gal. (91 L); SJ60 AJHE+ = 30.4 gal (115 L)
• Notable systems: SKYCODED™, ECO, ACCESSORYZERS™, EASYDRIVE™, AXLDRIVE™, SKYRISER™
