Poppet pneumatic directional control valve SX series
solenoid-operatedair-operated3-way

Poppet pneumatic directional control valve - SX series - SMC Corporation of America - solenoid-operated / air-operated / 3-way
Poppet pneumatic directional control valve - SX series - SMC Corporation of America - solenoid-operated / air-operated / 3-way
Poppet pneumatic directional control valve - SX series - SMC Corporation of America - solenoid-operated / air-operated / 3-way - image - 2
Add to favorites
Compare this product

Characteristics

Type
poppet
Actuating method
air-operated, solenoid-operated
Ports/positions
3-way, 2-way
Function
normally closed
Other characteristics
compact
Operating pressure

Max.: 200,000 Pa
(29.01 psi)

Min.: -100,000 Pa
(-14.5 psi)

Flow rate

22 l/min, 45 l/min, 90 l/min
(5.8 us gal/min, 11.9 us gal/min, 23.8 us gal/min)

Description

SX90 and SX090 are low profile 2/3 Port Direct Operated Poppet Style Solenoid Valves for Air and Inert Gases. The 2 port SX90 can provide large flow rate of 45 L/min from its compact body. The 3 port SX090 can provide large flow rate of 90 L/min from its compact body. Example applications for SX90 and SX090 are blood pressure measuring device, portable oxygen concentrator, chip mounter, air blow and sorting. • Enclosure: IP40 • Voltage: 12 VDC, 24 VDC • Available with power saving circuit to hold the actuation: 0.7W during holding
