XY stage KDT180-NM

linear motor-driven2-axishigh-accuracy

High-precision with 100 mm travel, aperture 115 mm, 0.5 µm repeatability, 5 kg load Equipped with piezo motors, the KDT180 is impressive with the smallest increments and high resolution. The XY stage achieves high speed at the same time as high positioning resolution. This XY system is also available as a high vacuum, ultra-high vacuum and non-magnetic version for demanding ambient conditions. Suitable for demanding environments • Ideal for microscopy, research and development and experimental physics • High-precision repeatability up to 0.5 µm • High speeds with very high positioning resolution • Optional with piezo motor, stepper motor or DC motor • Vacuum version (HV / UHV) and non-magnetic variants available Fields of application High resolution applications in microscopy, super resolution microscopy, scanning microscopy, 3D imaging, screening, vacuum chambers, interferometry, metrology, autofocus systems, biotechnology, semiconductor testing, research, experimental physics, electronics assembly, optics positioning, sample positioning
