Hydraulic press 2200 RP - Rail

manualbendingstraightening

The “2200 RP” stationary rail bending and straightening system is used for universal bending and straightening in rail and points construction. The horizontal design facilitates simple handling and transport of the rails. With the long cylinder stroke, the rails can be machined upright or horizontally. The tool height of 300 mm allows for straightening and bending of all standard rail profiles. As an option, the abutments can be set electro-mechanically to the rail profile required. With the quick-change tool system, the machine can be refitted for a different rail profile very quickly. The operator is assisted by the manual control with fine stroke adjustment which is easy to operate. An optional laser system supports the operator with bending and straightening the rails: Bending grooved rails Bending Vignoles rails Bending and straightening tongue rails (tongue rail straightening machine) Bending full-web rails Bending special rails Bending rails by folding Straightening rails Torsion straightening of rails Straightening frogs Control The manual control is available for all horizontal bending and straightening machines. It has proved itself over decades of use and is easy to use for any member of staff. The fine stroke adjustment allows precise bending and straightening. Simple and easy setting of the cylinder advance and return position with the tried and tested Stierli switch-off system with Vernier scale and 0 mark. (Stroke limitation) Precise bending and straightening with fine stroke adjustment. Continuous speed regulation from 0 to 0.6 m/min. Continuous pressure regulation with separate pressure gauge display.
