Stainless steel lid stay S-AT01, S-AT02
for heavy loadsspring

stainless steel lid stay
stainless steel lid stay
stainless steel lid stay
stainless steel lid stay
stainless steel lid stay
stainless steel lid stay
stainless steel lid stay
stainless steel lid stay
stainless steel lid stay
Add to favorites
Compare this product


Characteristics

Options
stainless steel, for heavy loads, spring

Description

LIFT ASSIST STAY (Side Mount) Features ●Spring mechanism assists in lifting the top-opening lid. ●Easily holds the door at any angle (about 10°~80°). ●Compact design maximises the space inside. ●Side mount and back panel mount are available. Both are nonhanded. ●Can select spring tension hard or soft type depending on lid weight and dimension. ●S-AT02W with doubled maximum door moment also available. [Specifications] ●Operating temperature: 0℃~40℃ ●Operating humidity: 90%RH or less ●For other specification exceeding the above range, please contact local representatives. [Remarks] ●Be sure to read the “Cautions” . ●When used for the top-opening lid, install a stopper (not included) to prevent from exceeding the opening angle. ●Material of the mounting surface should be take into consideration. Low rigidness may cause deformation or damage. ●Continuous opening and closing is not allowed. ●Do not use outdoors. ●Spring tension may vary over time. ●Do not use concealed hinges (multiaxial hinges). ●We recommend to test the assembly before final use.

VIDEO
