Planetary gear reducer Hansen P4

coaxialsolid-shaft> 10 kNm

Increased bearing span for robustness against high overhung loads. Mounting feet symmetric around low speed shaft to evenly distribute loads. Service friendly with split plane and maintenance-free sealing system. Powerful Hansen P4 gear geometry for low noise and vibration levels. Designed for heavy-duty applications: Cooling towers, Mixers, Toasters, Pulpers and more. Advantages of Hansen P4 Vertical Series Dedicated Vertical Housing Rounded design, Smooth transition of high forces from centre bore to mounting feet Extreme High Overhung Loads A wide range of Robust bearing arrangements and flange configurations Maintenance-Friendly Split Housing Horizontally above the oil level for ease of inspection and maintenance Leakage-Free Sealing Systems Drywell at the low speed shaft and maintenance free Oil-lock at the high speed shaft Reliable Lubrication Lower oil level, Less losses, Better thermal rating & Longer oil life Instruments & Accessories Condition monitoring instruments, Cooling devices & Complete Drive Packages (including base plates or lantern housings, motors, couplings,...) ATEX / UKCA EX certification Certification for explosive environments Extreme High Overhung Loads Rigid dedicated Hansen P4 housing design to ensure smooth transition of high forces from the centre bore to the mounting feet, which are positioned concentric to the low speed shaft. Possibility for extended bearing housing integrated in the housing casting and a wide range of robust bearing arrangements provides extremely high thrust load and bending moment capacity. Oil-tight drywell The standard integrated drywell prevents oil from leaking along the low speed shaft at any circumstances.
