CNC drilling machine CNC5040verticalEDM
Add to favorites
Compare this product
Characteristics
- Type
- CNC
- Structure
- vertical
- Other characteristics
- EDM
- Drilling diameter
Max.: 3 mm
(0.12 in)Min.: 0.2 mm
(0.01 in)- Power
3,500 W
- Weight
900 kg
(1,984 lb)
Description
1. High-Speed Machining:Processing speed up to 30–60 mm/min (material-dependent), significantly reducing cycle time.
2. Ultra-Deep Micro-Hole Capability:Machines holes from Φ0.15 to 3.0 mm with a depth-to-diameter ratio up to 300:1, saving 15% on electrode tube consumption.
3. Direct Machining on Complex Surfaces:Performs hole drilling directly on inclined or curved workpiece surfaces—no pre-treatment required.
4. Safe Broken Tool Removal:Easily erodes broken drills and taps from the workpiece without damaging the original threads.
5. One-Touch Electrode Replacement, quick and hassle-free.
6. Flexible Programming & Path Simulation:Supports both point-by-point and array/formula-based hole programming, with a visual path preview to simulate machining sequence before cutting.
2. Ultra-Deep Micro-Hole Capability:Machines holes from Φ0.15 to 3.0 mm with a depth-to-diameter ratio up to 300:1, saving 15% on electrode tube consumption.
3. Direct Machining on Complex Surfaces:Performs hole drilling directly on inclined or curved workpiece surfaces—no pre-treatment required.
4. Safe Broken Tool Removal:Easily erodes broken drills and taps from the workpiece without damaging the original threads.
5. One-Touch Electrode Replacement, quick and hassle-free.
6. Flexible Programming & Path Simulation:Supports both point-by-point and array/formula-based hole programming, with a visual path preview to simulate machining sequence before cutting.
