CNC drilling machine BH5040
vertical3-axisdeep hole

CNC drilling machine - BH5040 - SXKH GLOBAL - vertical / 3-axis / deep hole
CNC drilling machine - BH5040 - SXKH GLOBAL - vertical / 3-axis / deep hole
Add to favorites
Compare this product
Go to the SXKH GLOBAL website for more information

Characteristics

Type
CNC
Structure
vertical
Number of axes
3-axis
Applications
for steel, deep hole, for metal plates, for molds
Other characteristics
EDM
Drilling diameter

Min.: 0.3 mm
(0.01 in)

Max.: 3 mm
(0.12 in)

Power

3,500 W

Weight

750 kg
(1,653 lb)

Description

  • 1. High-Speed Machining:Processing speed up to 30–60 mm/min (material-dependent), significantly reducing cycle time.

  • 2. Ultra-Deep Micro-Hole Capability:Machines holes from Φ0.3 to 3.0 mm with a depth-to-diameter ratio up to 300:1, saving 15% on electrode tube consumption.

  • 3. Direct Machining on Complex Surfaces:Performs hole drilling directly on inclined or curved workpiece surfaces—no pre-treatment required.

  • 4. Safe Broken Tool Removal:Easily erodes broken drills and taps from the workpiece without damaging the original threads.

  • 5. One-Touch Electrode Replacement, quick and hassle-free.

  • 6. Flexible Programming & Path Simulation:Supports both point-by-point and array/formula-based hole programming, with a visual path preview to simulate machining sequence before cutting.
