Vertical storage carousel

for pipesfor textilesfabric roll

Product Overview: Rotating storage system – Automated vertical carousel for rolls and bobbins. Designed for the automatic storage and ergonomic handling of rolls and bobbins, ideal for flexible floor coverings, technical materials, packaging, and wrapping rolls. Applications: - Flexible floor coverings - Technical materials (fibreglass, tarpaulins, coated sheet, etc.) - Packaging/wrapping rolls Storage Method: - Rolls/bobbins are stored on the correct axle for their inner diameter (use load calculation to determine the right axle diameter to prevent flexion). - Material can be pulled from the roll mounted on the carousel by a fabric cutting or inspection machine, or simply onto a table for end-cutting and quilting. - Axle position is adjustable on the drive chain for stock optimisation. - Available in one loop and multiloop versions, depending on total cumulative load. Options and Accessories (depending on configuration): - Centring cones - Flange guide - Roller axle - Securing straps - Label holder - Regulator for start/end of cycle (depending on overall load) - Cell rail - Dual forwards/backwards control - Manual or automatic cutting table - Measuring system - Unrolling cradle - Pay-out reel on wheels (e.g., crank cylinder) Loading/Unloading: - Dedicated load handling truck for ergonomic loading on the lower section - Several truck types available, including battery-powered load handling trucks Technical Features: - 13 heights available - 5 ranges available depending on maximum diameter - 3 types of drive chain - Max. weight: 1000 kg - Max. diameter: 980 mm - Total length: 2 to 6.5 metres - Linear speed: 4 to 6.10 m/min. maximum - Control: Press and hold or automated - Power supply: 220 V or 380 V – 0.55 kW to 1.5 kW Specifications Sheet: - Outer diameter of roll - Inner diameter of roll - Maximum width - Maximum weight - Quantity for storage - Single- or double-sided use - Heights available - Supply of a manual or automatic cutting table - Press and hold or automated control - Other possible restrictions (ATEX zone, power supply system, etc.) Key Advantages: - Easy to use: Default control method is pressing and holding the button to reach the desired item. The carousel can be rotated in both directions. - Safe to operate: Ergonomic work height for loading and unloading, no risk for employees. - Quick access: Press and hold the button or enter the location code to quickly reach the right item. - Optimised space: Makes use of building’s overhead space. - Stock management: Faster stocktaking, can be integrated with ERP and WMS for optimised management. - Heavy and bulky product storage: Specific products for every application. Control Options: - Forward or Reverse press button - Control with tactile screen Characteristics / Technical Specifications: - 13 heights available - 5 ranges by maximum diameter - 3 types of drive chain - Max. weight: 1000 kg - Max. diameter: 980 mm - Total length: 2 to 6.5 m - Linear speed: 4 to 6.10 m/min - Control: Press and hold or automated - Power supply: 220 V or 380 V – 0.55 kW to 1.5 kW
