Shock resistant enclosure BDN seriesfloor-standingrectangularcast aluminum
Add to favorites
Compare this product
Characteristics
- Construction
- floor-standing
- Configuration
- rectangular
- Material
- cast aluminum
- Application
- industrial, electronic equipment, for electronics, field instrument
- Protection level
- watertight, weather-resistant, impact-resistant, shock resistant, shock resistant, IP67, with EMI shielding
- Other characteristics
- sealed, screw cover, die-cast
- Width
Max.: 160 mm
(6.3 in)Min.: 60 mm
(2.4 in)- Height
Max.: 90 mm
(3.5 in)Min.: 50 mm
(2 in)- Depth
Max.: 260 mm
(10.24 in)Min.: 80 mm
(3.15 in)
Description
Shock-resistant & waterproof diecast aluminium box.
Equipped with an O-ring for water- and dust-proofing.
N type with unfinished surface can be used as a shielded box, as it is conductive.
Specifications
See TAKACHI website for accessories and optional parts.
Equipped with an O-ring for water- and dust-proofing.
N type with unfinished surface can be used as a shielded box, as it is conductive.
Specifications
- Material : Diecast aluminium ADC12
- Protection class : IP67
- Operating temperature : -40°C ~ +105°C
- Conductive models available.
- 8 sizes available.
- Available in Light Grey or Natural (unfinished, conductive) finishes.
See TAKACHI website for accessories and optional parts.
