plasma surface treatment machine plasma surface treatment machine - VacuTEC
{{requestButtons}}

Characteristics

  • Type:

    plasma

  • Other characteristics:

    vacuum

Description

Tantec´s VacuTEC Plasma Treater is designed for plasma treatment of a large number of different injection moulded parts.

The VacuTEC is available with both single and multiple tray configuration.

The VacuTEC offers very fast treatment times and optimum adhesion properties for downstream coating, gluing, painting and printing applications. In the vacuum treating chamber a vacuum is built up to between 2 and 12 mbar before an electrical discharge is created through the integrated plasma electrode. Treatment cycle times are often short, between 2-120 seconds depending on the material and its formulation.

The VacuTEC is appreciated for its simplicity of operation, reliability in production and fast process speed. Treating gasses such as argon and oxygen can be applied, but in most cases this is not necessary due to the high power exposed by the plasma discharge.

VacuTEC uses the advanced Tantec power generator HV-X series as power supply and specially designed plasma transformers to provide voltage to the plasma electrodes.
