Tabletop power supply GPP-3323
AC/DCtriple-outputlaboratory

Tabletop power supply - GPP-3323 - Tecpel Co., Ltd. - AC/DC / triple-output / laboratory

Tabletop power supply - GPP-3323 - Tecpel Co., Ltd. - AC/DC / triple-output / laboratory - image - 2

Tabletop power supply - GPP-3323 - Tecpel Co., Ltd. - AC/DC / triple-output / laboratory - image - 3

Tabletop power supply - GPP-3323 - Tecpel Co., Ltd. - AC/DC / triple-output / laboratory - image - 4

Tabletop power supply - GPP-3323 - Tecpel Co., Ltd. - AC/DC / triple-output / laboratory - image - 5

Tabletop power supply - GPP-3323 - Tecpel Co., Ltd. - AC/DC / triple-output / laboratory - image - 6

Add to favorites

Compare this product

Go to the Tecpel Co., Ltd. website for more information

Characteristics

Mounting / format: tabletop
Type: AC/DC
Output: triple-output
Applications: laboratory
Other characteristics: programmable

Description

GPP-3323 Three Channel（CH1：0~32V / 0~3A，CH2：0~32V / 0 ~3A，CH3：1.8V，2.5V，3.3V，5.0V / 5A）、 4.3" TFT LCD screen Supports setting value, measured value and waveform output display E-Load function (CC, CV, CR mode) Setting resolution: 1mV/0.1mA; readback resolution: 0.1mV/0.1mA Low ripple noise: ≦350uVrms/ ≦2mArms Transient response time: ≦50uS Hardware design OVP/OCP/OTP protection Delay/output monitoring/output recording function Intelligent temperature-controlled fan design effectively reduces noise Sequence output function and built-in 8 sets of model waveforms Output recording function records output voltage and current parameters (minimum recording interval 1 second) Provides 10 sets of internal memory per sequence/delay/record/panel setup condition Standard interface: RS-232, USB, Ext I/O; Optional: LAN, GPIB+LAN Compatible with GPD-x303S series instructions
