Digital circuit breaker TemBreak PRO

solid-statesingle-phasedigital

Product overview
TemBreak PRO series replaces the TemBreak2 range and provides molded-case circuit breakers (MCCB) and earth-leakage circuit breakers covering broad frame sizes. MCCBs are available from 30 A to 3200 A; earth-leakage circuit breakers from 30 A to 800 A.

Electronic types

• Standard electronic breakers with simplified protection setting options.
• Smart breakers with measurement display (current, voltage, power) and Modbus RTU network communication.

Features

• New products added in the 100 A to 630 A frames to extend the range.
• Reduced outline dimensions for Standard and Current-limiting series to optimize panel space.
• Smart breakers offer improved measurement accuracy and user convenience (display, configuration, communication).

Molded-case circuit breakers (examples)

• Economical series
• Standard series
• High-fault level series
• Current-limiting series
• Motor protection series
• Switch-disconnectors
• Non-automatic trip breakers
• Circuit breakers for distribution boards

Circuit breakers for European market (selection)

• Economical series
• Standard series
• High-fault series
• Current-limiting series
• Switch-disconnector
• Non-automatic trip breakers

Earth leakage circuit breakers

• Economical earth-leakage series
• Standard earth-leakage series
• High-fault level earth-leakage series
• Earth-leakage breakers for motor protection
• Single-phase 3-wire earth-leakage breakers with neutral-phase loss protection
• Earth-leakage breakers for distribution and control boards

Molded-case circuit breakers for DC special voltage

• MCCBs for 350 Vdc–600 Vdc
• MCCBs for 750 Vdc–1000 Vdc
• Switch-disconnectors for 600 Vdc–1000 Vdc

Software
Some TemBreak PRO products include open-source software; copyright and licence conditions for included software are provided in the product documentation.

Technical specifications

• Rated current range (MCCB): 30 A to 3200 A.
• Rated current range (Earth-leakage): 30 A to 800 A.
• Electronic breaker types: Standard (simple protection settings) and Smart (measurement display, Modbus RTU communication).
• Expanded lineup covering 100 A–630 A frames.
• Mechanical: reduced outline dimensions for selected Standard and Current-limiting models to save panel space.
• Smart breaker functions: high measurement accuracy, on-device display, and Modbus RTU network communication.
• DC product ranges: 350 Vdc–600 Vdc and 750 Vdc–1000 Vdc; switch-disconnectors for 600 Vdc–1000 Vdc.
• Software: open-source components may be included; see accompanying documentation for licence details.
