Power quality measuring instrument AFLEX-3005

AC voltagecurrentAC

AC current measurement up to 3000A (True RMS): basic accuracy 1% of range AC voltage measurement up to 600V (True RMS): basic accuracy 0.5% of range AC watt measurement up to 9999KW: basic accuracy 1% of range Power quality analysis for single and balanced 3 phase system Measurement of balanced 3Φ power quality and phase sequence Active (W, KW, HP), Reactive (VAR, KVAR) and Apparent (VA, KVA) power Power factor (PF), Phase angle (Φ), and Energy (WH, KWH) 1 to 50th order of harmonics at 2.0% basic accuracy Total harmonic distortion (%THD-F) and Crest factor (CF) Frequency of ACV or ACA: 45 ~ 65 Hz Fast peak function (39μs for 50 Hz, 33μs for 60Hz) Work with PC via USB interface Programmable CT ratio from 1 to 250 Max / Min / Data Hold functions Auto power off function in 30 minutes Data logging memory size: 8000 records
