Double-sided adhesive tape EasySplice® 51786

flatback paperpaper lineracrylic

Product description
tesa® 51786 EasySplice Detect Plus is a double-sided flying splice tape composed of a metallised flat-back paper backing and an acrylic adhesive. Paper-based materials are produced from responsibly managed forests and controlled sources. Colour: orange/silver.

Features

• Very high initial tack
• Very high shear resistance
• Excellent heat resistance
• Best adhesion on coated and uncoated paper
• Low splice thickness
• Reliable detection of splice position
• Smooth and easy application due to a flexible backing
• Available with one or two splitting strips with paper backing for controlled opening of the new reel

Innovative tape composition / Functions

• Split liner for secure fixation of the top sheet
• Metallised backing enables reliable splice position detection
• Acrylic adhesive formulation with very high tack for excellent contact between expiring web and new reel
• Optional one or two splitting strips with paper backing for smooth reel opening without jeopardising the printing process
• Colour: Orange

Application Fields
Designed for flying splices in web-fed printing and continuous roll change applications.

Product Construction
Backing material: Aluminised paper
Colour: orange/silver
Total thickness: 110 µm

Properties / Performance Values
Elongation at break: 6 %
Tensile strength: 36 N/cm
Shelf life (packed, < 25°C): 18 months

Technical characteristics

• Backing material: aluminised flat-back paper
• Adhesive: acrylic, very high initial tack
• Colour: orange/silver
• Total thickness: 110 µm
• Elongation at break: 6 %
• Tensile strength: 36 N/cm
• Shelf life (packed, < 25°C): 18 months
