Indoor air quality sensor NOVOS 7 move

roomCO2relative humidity

The portable stand-alone solution of NOVOS 7 move simplifies the monitoring of indoor air quality and is able to initiate necessary measures improving the air quality. The practical desk display and the connected power supply unit make it possible to use the NOVOS 7 for CO2 measurement as a “plug & monitor” solution. The intelligent traffic light function uses a TFT display and an acoustic signal to indicate when it is time to take appropriate action. For example, the yellow or red background indicates, that the CO2 concentration in the ambient air is too high and the room should be ventilated. • Application/type : CO2 Traffic Light, Room sensor • Purpose : Measure values • Measured values : temperature, relative humidity, CO2 • Operating elements : 4 favourite buttons • Configuration : NOVOSapp, uConfig • Operating range temperature (°C) : 0..+50 • Operating range humidity : max. 85% rH non-condensing • Accuracy temperature : ±0,5 K (typ. at 21 °C) • Measuring range humidity : 0..100% rH non-condensing • Accuracy humidity : ±2% between 10..90% rH (typ. at 21 °C) • Measuring range CO2 : 0..5000 ppm • Accuracy CO2 : ±50 ppm +3% of measured value (typ. at 21 °C, 50% rH, 1015 hPa), self-calibration Dual Channel • Power supply : 15..35 V = SELV, 19..29 V ~ SELV, mains adapter 100..230 V (50/60 Hz), max. 0,4A, Flush-mounted power supply 230 V (±10%, 50/60 Hz), max. 0.4 A • Display : TFT 3,5", 320x480 px, with traffic light function, threshold values configurable, optionally configurable via app or uConfig • Enclosure : PC V0 • Colour : pure white • Protection (IP) : IP30, according to EN 60529
