Power cable MV-ABCinsulatedwith copper screenstranded
Add to favorites
Compare this product
Characteristics
- Type
- power
- Protection
- insulated, with copper screen
- Configuration
- stranded, spiral, circular
- Applications
- distribution, overhead
- Material of the insulation
- XLPE-insulated, polyethylene
- Norms
- IEC
- Other characteristics
- coated, high-density
- Nominal voltage
Min.: 0 kV
Max.: 45 kV
- Temperature
90 °C
(194 °F)- Cross-section
Min.: 35 mm²
(0.05 in²)Max.: 185 mm²
(0.29 in²)
Description
Aerial bundled cables
Standards: AS 3599.1
Construction: Al/XLPE/CWS/HDPE
Conductor: Stranded compacted circular aluminium
Conductor screen: Semi-conductive compound
Insulation: XLPE
Insulation screen: Semi-conductive compound
Metallic screen: Copper wires (or copper tape)
Binder: PET
Outer sheath: HDPE
Support catenary: Zinc- Coated steel wires, concentric stranded (in center or in spiral together with cores)
Cable identification: with color tapes lie between insulation screen and metallic screen
Cores: Red, yellow, blue
Outer sheath: Black
The above identifying can be changed as order
Used for overhead power transmission lines and power distribution.
