Laser cutting machine TH-RCF series

fiber laser3D laserfor stainless steel

Overview
Three-dimensional fiber laser cutting machine designed for high-speed 3D cutting of medium and thin metal plates such as carbon steel and stainless steel. Cutting thickness and speed depend on laser power and material properties. Suitable for automated production lines and complex part geometries.

Features

• Integration of a fiber laser cutting system with a six-axis industrial robot for full 3D trajectory cutting
• Two main structural configurations available: floor-standing and top-mounted
• Recommended six-axis robot brands: ABB and Staubli; compatible with other industrial robots
• Customizable 3D cutting workbench and positioning/clamping mechanisms to fit specific parts
• Ability to switch functions between fiber laser cutting and laser welding for increased process flexibility
• Option for dual-robot special-shaped tube cutting to handle complex profiles

Sample display
Cutting samples illustrating 3D cutting capability, edge quality and typical part geometries are provided for reference.

Technical specifications

• Commodity name: 3D Laser Cutting Machine
• Commodity ID: 1475857268568903680
• Model(s): TH-RCF1550A, TH-RCF2010S
• Laser power: 500W ~ 1500W
• Robot brand and model: ABB IRB2400 (TH-RCF1550A); Staubli RX160L (TH-RCF2010S)
• Robot machining radius: 1550mm (TH-RCF1550A); 2010mm (TH-RCF2010S)
• Robot trajectory accuracy: 0.15mm (TH-RCF1550A); 0.14mm (TH-RCF2010S)
• Robot repeatability: 0.06mm (TH-RCF1550A); 0.05mm (TH-RCF2010S)
• Robot rated load: 20Kg (TH-RCF1550A); 14Kg (TH-RCF2010S)
• Robot weight: 380Kg (TH-RCF1550A); 250Kg (TH-RCF2010S)
