Overview The Tripp Lite SmartPro SMX2200XLRT2U is a 2.2 kVA / 1.92 kW line-interactive UPS designed to provide network-grade power protection for servers, network and telecom equipment. It features automatic voltage regulation (AVR) to correct brownouts and overvoltages, hot-swappable internal batteries and options for external battery packs to extend runtime.

Key features

• 2.2 kVA (2200 VA) / 1920 W line-interactive UPS with pure sine wave output
• 2U rack/tower convertible form factor; front-panel LCD rotates for rack or tower use
• Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages (input range 158–278 V)
• High line-mode efficiency (approx. 98%) to reduce heat and operating costs
• Two independently switchable output load banks (remote reboot/load shedding)
• Interactive LCD displaying UPS mode, battery charge and site-power data
• Built-in USB and RS-232 communications; slot for optional network management cards (WEBCARDLX / TLNETCARD / RELAYIOCARD)
• HID-compliant USB for OS auto-shutdown; supports PowerAlert monitoring software
• Emergency Power Off (EPO) interface
• Hot-swappable internal VRLA battery cartridge; optional external battery packs for extended runtime

Package Includes

• SMX2200XLRT2U UPS system (Tripp Lite SmartPro)
• USB, serial and EPO cabling
• 4-post rackmount installation kit
• Set of three C13/C14 output power cables
• Instruction manual

Certifications / Compliance

• RoHS compliant
• CE
• GOST (Russia)
• Cisco compatibility (interoperability tested)
• VMware-ready (application)

Technical specifications

• Output capacity: 2200 VA (2.2 kVA) / 1920 W (1.92 kW)
• Power factor: 0.87 (0.9 PF available on some configurations)
• Nominal output voltages supported: 220 V / 230 V / 240 V; frequency 50/60 Hz (auto-select)
• Input: IEC C20 inlet (max input ≈ 11 A); nominal input 230 V AC
• Output receptacles: 8 × C13
• Load management: two switchable single-outlet C13 load banks (remote switching supported)
• Waveform: sine wave (AC mode) / pure sine wave (battery mode)
• AVR details: trims/reduces voltage across ranges (boost and buck modes for 158–278 V input)
• Transfer times: typical AC→battery 6 ms; DC→AC 1 ms
• Battery type: internal VRLA (valve-regulated lead-acid); hot-swappable cartridge (RBC94-2U)
• Runtime: ~5 min at full load (1920 W); ~11.9 min at half load (960 W); expandable with external battery packs (BP48V24-2U limit 1; BP48V60RT3U and BP48V27-2US multi-pack compatible). Note: some configurations may limit max output to 1600 W when external packs are connected
• Battery recharge: < 4.5 hours from 10% to 90% (typical, full-load discharge)
• Physical: 2U rack height; dimensions (H×W×D): 89 mm × 445 mm × 495 mm
• Weight: unit ≈ 31.2 kg (68.75 lb); shipping ≈ 36.78 kg (81.05 lb)
• Operating environment: 0° to 40°C; storage -15° to 50°C; 0–95% non‑condensing humidity
• Noise level: 45 dBA max at 1 m (front)
• Surge/noise suppression: EMI/RFI filtering; surge joule rating 350
• Included accessories: 4-post rail kit for 19" racks; optional mounting accessories available (2POSTRMKITWM, 2-9USTAND, 4POSTRAILKITWM, UPSHDEARKIT)
• Warranty: 2-year limited warranty
