Rack-mount power supply CPX Seriestabletop3UAC/DC
Add to favorites
Compare this product
Characteristics
- Mounting / format
- rack-mount, tabletop, 3U
- Type
- AC/DC
- Output
- single-output, regulated, dual-output
- Connection
- with USB outlet
- Applications
- laboratory, for remote control
- Other characteristics
- programmable, digital, compact
- Input voltage
Min.: 110 V
Max.: 240 V
- Output voltage
Min.: 0 V
Max.: 60 V
- Current
Min.: 0 A
Max.: 20 A
- Power
360 W, 420 W, 840 W
Description
Bench/System/ATE Programmable DC Power Supply Single or Dual Outputs, 360 to 840 watts, with or without Remote Interfaces
• PowerFlex design gives variable voltage and current combinations within a maximum power range
• Up to 60 volts and up to 20 amps
• 180 watts or 420 watts maximum per output
• Isolated outputs can be wired in series or parallel
• Constant voltage or constant current operation
• Settings Locking (S-Lock)
• PowerFlex or fixed-range operation
• Variable OVP trips
• Selectable remote sense terminals
• Compact quarter or half rack 3U case size
• Isolated analogue remote control (CPX400SA only)
• RS232, USB & LXI compliant LAN (P models only)
• GPIB Option (P models only)
