Mobile truck-mounted concrete pump Adroit 250E/Goutdoorfor constructionand shotcrete
Add to favorites
Compare this product
Characteristics
- Configuration
- mobile
- Applications
- for construction, outdoor
- Other characteristics
- and shotcrete
- Output
Max.: 30 m³/h
(1,059.4 ft³/h)Min.: 22 m³/h
(776.9 ft³/h)- Pumping pressure
60 bar, 70 bar
(870.2 psi, 1,015.3 psi)- Power
45 kW, 55 kW
(61.2 hp, 74.8 hp)- Width
2,500 mm
(98 in)- Length
7,500 mm, 9,500 mm
(295 in, 374 in)- Height
Max.: 3,800 mm
(150 in)Min.: 3,500 mm
(138 in)- Weight
Max.: 7,100 kg
(15,653 lb)Min.: 4,800 kg
(10,582 lb)
Description
Overview
Truck-mounted Adroit 230E/G and 250E/G series shotcrete machines combine a compact concrete pumping unit, folding telescopic boom, additive and water pumps and tanks, cable reel and compressor on a single vehicle designed to travel on highways. A generator can be fitted on request. The Adroit 250E/G integrates both shotcrete and concrete pumping functions through its specialized concrete pumping unit.
Main features
Additional information
The truck-mounted configuration eliminates transport issues between construction sites and enables immediate operation on arrival. Concrete pumping capacity is adjustable to application requirements. The vehicle is supplied with folding telescopic boom, additive and water pumps and tanks, cable reel and compressor; generator optional on request.
Technical specifications
Truck-mounted Adroit 230E/G and 250E/G series shotcrete machines combine a compact concrete pumping unit, folding telescopic boom, additive and water pumps and tanks, cable reel and compressor on a single vehicle designed to travel on highways. A generator can be fitted on request. The Adroit 250E/G integrates both shotcrete and concrete pumping functions through its specialized concrete pumping unit.
Main features
- Pumping capacity: 30 m³/h (250 series); 22 m³/h (230 series)
- Boom reach: 13.5 m lateral, 16 m vertical
- Compressor capacity: 9.2 m³/min
Additional information
The truck-mounted configuration eliminates transport issues between construction sites and enables immediate operation on arrival. Concrete pumping capacity is adjustable to application requirements. The vehicle is supplied with folding telescopic boom, additive and water pumps and tanks, cable reel and compressor; generator optional on request.
Technical specifications
- Model series: Adroit 250E/G and Adroit 230E/G
- Standard pumping capacity: 30 m³/h (250 series); 22 m³/h (230 series)
- Concrete pumping capacity: adjustable
- Lateral reach (boom): 13.5 m
- Vertical reach (boom): 16 m
- Compressor capacity: 9.2 m³/min
- Equipment mounted on truck: compact concrete pumping unit, folding telescopic boom, additive pump, water pump and tanks, cable reel, compressor
- Optional generator can be fitted on vehicle
- Design enables immediate operation on-site after arrival
- Adroit 250E/G: combined shotcrete and concrete pumping capability
