Water washing machine LFC-BS series

automaticfor the textile industryfor hospitals

The LFC-BS washer extractor is a guarantee for hygiene, offering maximum efficiency and disinfection. Designed for hospitals, clinics, and all types of health facilities that adhere to the strictest regulations and hygiene standards. - Robust construction with high-speed extraction capabilities. - Capacities range from 100 kg / 220 lb to 300 kg / 660 lb. - Equipped with double loading and unloading doors to prevent contamination. - Suspension system with four hydraulic shock absorbers. - Free-standing design, no need for anchorages. - Drum with three compartments and double shaft support. - Fully automated microprocessor control. - Automatic dispensers for 5 reservoirs. - Water inlets with automatic liter/gallon counter. - Sanitary barrier system with independent double door for front loading and back door discharge. Accessories: - Additional tanks - pH valve water intake - Supplementary water inlet - Double drain Technical Specifications: - Capacities: 105/160/200/300 kg (230/350/440/661 lb) - Drum Diameter: 1,250 to 1,700 mm (49.2 to 67 in) - Drum Depth: 864 to 1,260 mm (34 to 49.6 in) - Drum Volume: 1,060 to 2,860 liters (280 to 755.5 gal) - Compartments Number: 3 - Door Opening Area: 3,445 to 6,000 cm² (3.71 to 6.46 ft²) - Load Door Height: 947 to 1,177 mm (37.28 to 46.3 in) - Wash Velocity: 28 rpm - Centrifuge Speed: 600 to 650 rpm - Motor Power: 22 to 50 kW (30 to 70 hp) - Water Inlet: 2 in - Steam Inlet: 1 1/4 in - Drain: 120 to 200 mm (4.7 to 7.8 in) - Weight: 4,205 to 6,950 kg (9,250 to 15,322 lb) Dimensions: - Height: 1,890 to 2,560 mm (74.4 to 100.8 in) - Depth: 1,670 to 2,140 mm (65.75 to 84.2 in) - Width: 2,200 to 3,000 mm (86.61 to 118.1 in)
