Reflow soldering machine X-A300-LF

reflow soldering machine
reflow soldering machine
Add to favorites
Compare this product


wave, reflow


No. Item Specification 1.Dimension(mm):3200(L)X1250(W)X1650(H) (mm) 2.Color:Gray 3.Weight:1200KG 4Control system 4.1Control mode:Siemens PLC + touch screen dual control software 4.2Automatic Switcher function:automatically sets the system time 5.Spray system 5.1Spray mode:Automatic tracking spray 5.2 Nozzle moves:Standard:SMCrodless cylinder 5.3Nozzle:USATD Nozzle 5.4Flux Capacity:6L 5.5Flux Flow:10-100ml/min (adjustable) 5.6Spray pressure:0.25Mpa-0.5Mpa 5.7Spray sealing system:Seals all stainless steel, flux does not leak 6.Preheating system 6.1Temperature control :PID&SSR Control 6.2Temperature control accuracy:±1 ℃ 6.3Preheating zone temperature control range:Room temp.--250℃ 6.4Preheat zone length :1300mm 6.5Preheat zone number :2 6.6Preheat mode:Infrared preheat 6.7Preheat power"6KW MAX. 6.8Preheating temperature rise time"15Min,(Room Temp.~+150℃) 7.Welding system 7.1Tin furnace capacity:Leaded free solder paste 300KG 7.2Tin furnace materials:gall bladder and nozzle: 316L stainless steel 7.3Tin furnace power:10KW Max. 7.4Furnace temperature control accuracy:±1 ℃ 7.5Furnace maximum temperature:350℃ 7.6Furnace temperature control:PID+SSR Mode 7.7Furnace crest height adjustment:Inverter stepless adjustment 7.8Tin furnace temperature rise time:2hour 8.cooling system 8.1Cool power:1HP 8.2Cooling mode:adjustable turbo fan forced system 8.3Cooling speed:4℃~6℃/sec 9.Transport system 9.1Transport Mode:transport chain + titanium claws 9.2PCB board Transport mode :AUTO FEEDER MODE 9.3Conveyor Direction:Form left to right 9.4Conveyor Speed:0-2000MM/MIN (adjustable) 9.5Conveyor height adjust range:60-250MM 9.7Rail width adjustment :manual
