Gate valve 443with handwheelfor waterfor steam
Add to favorites
Compare this product
Characteristics
- Type
- gate
- Operation
- with handwheel
- Media
- for water, for steam
- Body
- flange, Y
- Applications
- for industrial applications, for heating, for refrigeration, for air conditioning
- Material
- cast iron
- Associated function
- balancing
- Other characteristics
- compact
- DN
Min.: 40 mm
(1.575 in)Max.: 300 mm
(11.811 in)- Pressure
16 bar
(232.1 psi)- Temperature
300 °C
(572 °F)
Description
high thightness (leakproofness class -Aacc. EN -12266 -1)
compact settlement
environment-friendly
tests acc. EN -12266 -1
flanges drilled according to EN 1092-2
face-to-face dimension according to EN 558-1 series 1
Aplications
industrial cold and hot water plants
heat engineering
industrial technologies
refrigeration and air conditioning
steam plants
