Hydrogen fuel cell HydraV VISTAH-110B

for vehiclesfor the automotive industry

Overview
The HydraV VISTAH-110B System is a traction battery system engineered for commercial electric vehicles and heavy-duty applications. It combines a modular platform architecture with standardized modules to simplify maintenance and enable flexible power configurations. The system is rated IP67 and supports cold start operation down to -30°C, ensuring functional reliability in harsh outdoor environments.

Application Scenarios

• Buses and commuter vehicles
• 18-ton sanitation and logistics vehicles
• Cold chain and insulated trucks

Battery Quick Facts
Rated Power: 110 kW
Volumetric Power Density: 485 W/L (manufacturer reference also mentions >500 W/L)
Gravimetric Power Density: 500 W/kg
Service Life: 30000 hours

Key Features

• Modular platform with standardized modules for straightforward maintenance and scalable capacity
• Cold start capability to -30°C for operation in low-temperature conditions
• IP67 protection rating for dust- and water-resistance in demanding environments
• Certification from the Chinese national testing center for reliability and stability
• Standard power ratings, sizes and electrical interfaces to support high compatibility with vehicle architectures

Technical specifications

• Model: HydraV VISTAH-110B System
• Rated power: 110 kW
• Volumetric power density: 485 W/L (page also references power density over 500 W/L)
• Gravimetric power density: 500 W/kg
• Service life: 30000 hours
• Cold start temperature: -30°C
• Protection rating: IP67 (waterproof and dustproof)
• Certification: Chinese national testing center
• Design: Modular platform with standardized modules, sizes and electrical interfaces
• Typical applications: buses, commuter vehicles, 18-ton sanitation and logistics vehicles, cold chain trucks
