Roll-fed form-fill-seal machine AM 8715 DP

for packagingfor food packaginghigh-speed

Product
AM 8715 DP is a flexible multi-purpose tube former designed for production of tubes for universal sacks, combining digital cross and longitudinal pasting. Available in two working widths (18–60 cm or 18–75 cm), it can be configured for agricultural, food and industrial sack manufacturing.

Your advantages

• FLYMATIC non-stop unwinders for continuous operation
• Up to 500 tubes/min production speed
• Digital Pasting for precise glue application
• Reduced glue consumption
• High tube quality

Applications

• Paper valve sacks
• Agricultural sacks
• Food packaging sacks
• Industrial sacks

Technical data
Number of plies: max. 3 or 4
Tube width: 18–60 cm or 18–75 cm
Tube length (flush-cut): 32–165 cm
Tube length (stepped-end cut): 38–150 cm
Machine speed: max. 500 pieces/min

Additional notes
Supports Digital Pasting; configurable for entry-level digital pasting workflows and integration with RUBY Essentials.

Specifications

• Model: AM 8715 DP
• Brand: Windmöller & Hölscher
• Working widths: 18–60 cm or 18–75 cm
• Number of plies: max. 3 or 4
• Tube length (flush-cut): 32–165 cm
• Tube length (stepped-end cut): 38–150 cm
• Production speed: up to 500 pieces/min
• Key features: FLYMATIC non-stop unwinders, Digital Pasting, reduced glue consumption
