Industrial tube assembly AM 8735

for food applicationscustom

Overview
AM 8735 is a universal tuber for multiwall paper sack production with digital cross- and seam pasting and easy set-up. The machine provides flexibility to cover a wide spectrum of sack types and production runs, including very small batches.

At a glance - Your advantages

• FLYMATIC non-stop unwinders for continuous feeding
• Output up to 500 tubes/min
• CNC control and digital cross- & seam pasting
• Minimized set-up and changeover times
• Consistent high tube quality

Applications

• Paper valve sacks
• Agricultural packaging
• Food packaging
• Industrial packaging

Product information
The AM 8735 is configurable to meet diverse production requirements and line conditions. Its digital pasting system allows precise glue placement for cross seams and longitudinal seams, enabling efficient processing of varied paper grades and small lot sizes. The machine integrates with upstream unwind systems and supports automated changeovers to reduce downtime.

Technical Data
Number of plies: max. 3 or 4
Tube width: 18 – 75 cm
Tube length, stepped end: 38 – 150 cm
Tube length, flush out: 32 – 165 cm
Output: max. 500 tubes/min

Characteristics / Technical specifications

• Model: AM 8735
• Brand: Windmöller & Hölscher
• Machine type: Universal tuber for multiwall paper sack production
• Glue application: Digital cross- and seam pasting (digital pasting)
• Unwinders: FLYMATIC non-stop unwinders
• Production output: up to 500 tubes/min (maximum)
• Number of plies supported: max. 3 or 4
• Tube width range: 18 – 75 cm
• Tube length (stepped end): 38 – 150 cm
• Tube length (flush out): 32 – 165 cm
• Designed for: paper valve sacks, agricultural, food and industrial applications
• Customizability: Configurable to diverse production requirements and conditions
