Plastic recycling unit

for photovoltaic panel treatementfor solar panelsfor process lines

Heating platform The photovoltaic panel heating platform equipment produced by our factory adopts stainless steel mesh belt conveyor, which can adjust the speed according to temperature efficiency. The hot air system adopts electric heating method, which has low energy consumption Without pollution and other characteristics, a row of fans is installed below for heat dissipation. Production capacity: 1000-1200kg/h Machine power: 30KW Size: 5000mm * 2000mm * 1800mm Weight: 1200KG Heating: Infrared heating tube, as well as regular heating rod Heating temperature: 110-130 degrees Celsius Photovoltaic panel glass removal machine This device is specifically designed for removing glass from photovoltaic modules, and can efficiently, quickly, and safely remove glass from photovoltaic modules with a glass removal rate of over 95%. Principle: Remove the aluminum frame and junction box from the photovoltaic panel and enter the heating chain conveyor. It is heated by constant temperature hot air to soften EVA and shape the photovoltaic panel before entering the glass removal machine. The glass removal machine head is equipped with 48 sets of white steel milling cutters, which remove glass through the reciprocating motion of the milling cutters. The dust generated during the glass removal process is collected by a set of pulse bag filters. The removed glass is transported by a fully enclosed belt to a grading screen, where glass particles and glass powder are separated to increase the value of the glass. Production capacity: 1000-1200kg/h Whole machine power: hydraulic 0.75KW+spindle 3KW Machine specifications: 1500 * 230mm * 1400mm Whole machine weight: approximately 1400KG
