Resistive touch screen panel PC W15IP7T-OFA2

15.6"Intel® Pentium® N42001366 x 768

Overview
Winmate W15IP7T-OFA2 is a 15.6-inch Intel® Pentium® N4200 open frame panel PC engineered for machine control, factory automation and operator HMI. The unit targets industrial integrators, OEMs and system builders requiring fanless operation, metal enclosure and flexible mounting for embedded installations.

Key features

• Intel® Pentium® N4200 (Apollo Lake), 1.10 GHz base (burst up to 2.5 GHz)
• Flexible storage: 1 x M.2 2242 SSD slot, optional 2 x SATA III for 2.5" drives
• Multiple I/O: 4 x USB 3.0 Type-A, 2 x Gigabit LAN, serial interfaces (RS232/422/485)
• Display outputs: DP1.2 (4096×2160@60Hz), HDMI 1.4 (3840×2160@30Hz) optional
• 12 V DC power input, fanless thermal design, metal housing

Display & ergonomics

• 15.6" panel, 1366×768 resolution, 400 nits brightness, 500:1 contrast
• Touch options: Resistive touch screen (optional) or protection glass without touch
• Viewing angles: 85/85/80/80; active area 344.232 × 195.536 mm

System & expansion

• Memory: 2 x SODIMM DDR3L 1866 MHz (4 GB default, 8 GB optional)
• Storage options: default M.2 2242 SSD (configurable up to 512 GB), optional 2 x SATA III for 2.5" SSD/HDD
• Expansion: M.2 2242 B-key (SATA), M.2 2230 E-key (Wi‑Fi), PCIe 2.0 x1 slot (optional)
• Security & OS: TPM 2.0; Windows 10 IoT Enterprise (64-bit) or Linux Ubuntu options

I/O & connectivity

• USB: 4 x USB3.2 Gen1 (Type-A)
• Serial: 1 x RS232/422/485 (default RS232) + 1 x RS232; optional serial configs
• LAN: 2 x Gigabit RJ45 (Intel® controllers)
• Audio: Mic-in, Line-out, 2 x speakers; indicators: power and storage LEDs

Mechanical & power

• Dimensions: 366.3 × 248 × 68.5 mm; Weight: ~3.9 kg
• Mounting: Open Frame, Panel Mount, VESA Mount
• Power: 1 x 12 V DC Din4 pin connector; adapter 12 V 50 W (accessory)

Environment & certifications

• Operating temperature: 0 °C to 50 °C; storage temperature: -10 °C to 60 °C
• Operating humidity: 10%–90% RH, non-condensing
• Certifications: CE, FCC

Typical applications

• Machine control and factory automation
• Operator HMI panels and control stations
• OEM embedded systems and industrial integration
