Manual punching machine PYE series
for aluminum profilesfor profilespunching

Manual punching machine - PYE series - YILMAZ MACHINE - for aluminum profiles / for profiles / punching

Manual punching machine - PYE series - YILMAZ MACHINE - for aluminum profiles / for profiles / punching - image - 2

Manual punching machine - PYE series - YILMAZ MACHINE - for aluminum profiles / for profiles / punching - image - 3

Add to favorites

Compare this product

Go to the YILMAZ MACHINE website for more information

Characteristics

Control

manual

Product handled

for aluminum profiles, for profiles

Associated function

punching, punching machine

Pressing force

Max.: 10,000,000,000 N

Min.: 0 N

X travel

Max.: 210 mm
(8.27 in)

Min.: 210 mm
(8.27 in)

Y travel

Max.: 180 mm
(7.09 in)

Min.: 180 mm
(7.09 in)

Plate thickness

Max.: 1.5 mm
(0.06 in)

Min.: 0 mm
(0 in)

Description

Product overview
Manual punch press machines for opening corner joint slots on aluminium profiles used in door and window systems. Four versions are available: PYE 101, PYE 102, PYE 103 and PYE 104.

General features

Opens corner joint holes/slots on aluminium profiles
Works on corner thicknesses up to 1.5 mm
Practical operation and ergonomic body design
Hardened special punch tool set
Usable inner dimensions (press): W 210 mm / H 180 mm
Height of die from blank: 100 mm

Versions

PYE 101
PYE 102
PYE 103
PYE 104

Standard accessories

Optional accessories

Technical specifications

Machine type: Manual punch press for aluminium profiles (corner/joint slot punching)
Application: Opening corner joint slots on aluminium profiles for door and window systems
Operations: Hole and slot punching
Models: PYE 101, PYE 102, PYE 103, PYE 104
Maximum corner thickness: up to 1.5 mm
Usable inner dimensions: Width 210 mm, Height 180 mm
Height of die from blank: 100 mm
Tooling: Hardened special punch tool set
Design: Ergonomic body for practical operations
