hydraulic hose / for high-pressure applications / for marine applications / agricultural
OL7 series

{{requestButtons}}

Characteristics

  • Use:

    hydraulic

  • Applications:

    for high-pressure applications, for marine applications, agricultural

  • Material:

    thermoplastic

  • Inner diameter:

    Max.: 25.6 mm

    Min.: 3.5 mm

  • Outer diameter:

    Max.: 33.6 mm

    Min.: 8.5 mm

  • Pressure:

    Max.: 250 bar (3,625.943 psi)

    Min.: 70 bar (1,015.264 psi)

  • Temperature:

    Max.: 100 °C (212 °F)

    Min.: -54 °C (-65.2 °F)

Description

Technical-constructive features:
Inner core in thermoplastic polyester, reinforcement in polyester textile and exterior covering in antiabrasion polyurethane stabilized against UV rays and resistant to hydrolysis and micro-organisms, suitable for outdoor applications in environments having high humidity and saline levels.

Applications:
Hoses of the OL7 Marine Series have been created for high pressure hydraulic applications in MARINE environments; this type of hose offers good flexibility at low temperatures and is particularly recommended for operating machines and lift trucks, which work at low temperatures.
