Primary shredder SPW150

double shaftpaperfor cardboard

Product Summary
Designed for efficient pre-shredding and size reduction of paper cores, cardboard and boxes to facilitate recycling and further processing.

Application
Used to shred waste cardboard, paper, boxes and paper cores in packaging, recycling and paper-processing facilities.

Advantages

• Robust shredding unit with industrial construction and straightforward operation.
• Frequency-controlled motor (example rating: 18.5 kW on some units) driving the cutting system.
• Cutters manufactured from specially hardened steel for extended wear life.
• Feeder controller regulates material feed for continuous operation under varying load.
• High throughput: capable of shredding up to 100 cores per hour (for cores up to 120 mm diameter and wall thickness up to 30 mm).
• Suitable for intermittent or continuous operation; shredded output is easy to handle and recycle.

Technical Data
Model: SPW150
Brand: GATOR
Maximum cardboard feeding width: 1500 mm
Maximum paper core shredding thickness: 30 mm
Maximum cardboard shredding thickness: 80 mm
Power: 15 kW
Shredding size: variable
Shredding capacity: 800-1500 kg per hour
Machine size: 2130(L) * 1630(W) * 1849(H) mm
Machine weight: 2800 kgs

Specifications

• Model: SPW150
• Brand: GATOR
• Maximum cardboard feeding width: 1500 mm
• Maximum paper core shredding thickness: 30 mm
• Maximum cardboard shredding thickness: 80 mm
• Power: 15 kW
• Shredding size: variable
• Shredding capacity: 800-1500 kg per hour
• Machine size: 2130(L) * 1630(W) * 1849(H) mm
• Machine weight: 2800 kgs
