Automatic filling machine bottlecontainerbeverage
Add to favorites
Compare this product
Characteristics
- Operational mode
- automatic
- Container type
- bottle, container
- Product applications
- food, beverage
- Domain
- for the food industry
- Type
- volumetric
- Other characteristics
- pneumatic, servo-driven
Description
Servo-Driven Rotary Lobe Pump Filling Machine The Servo-Driven Rotary Lobe Pump Filling Machine is a high-precision liquid filling system integrating the robust transfer capability of rotary lobe pumps with the intelligent control of servo motors.
It is widely used in pharmaceuticals, food & beverage, and cosmetics industries, especially for handling viscous, particle-laden, or foamy liquids (e.g., jams, pastes, sauces, detergents).
Key Features: Precision Dosing Servo motor-driven pump achieves ±0.5% filling accuracy with zero dripping or foaming.
Material Versatility Handles fluids up to 100,000cP viscosity and particles ≤5mm in diameter via rotating lobes. Hygienic Construction Wetted parts (316L stainless steel/food-grade silicone) comply with GMP/FDA hygienic standards. Smart Control PLC HMI interface enables recipe storage, output statistics, auto-alarm, and quick container changeover.
Energy Efficiency Servo system reduces energy consumption by 30% vs. pneumatic systems, with speeds up to 60 bottles/min (viscosity-dependent). Workflow: Bottle positioning → Material suction → Servo-quantified filling → Nozzle retraction → Conveying to next station.
It is widely used in pharmaceuticals, food & beverage, and cosmetics industries, especially for handling viscous, particle-laden, or foamy liquids (e.g., jams, pastes, sauces, detergents).
Key Features: Precision Dosing Servo motor-driven pump achieves ±0.5% filling accuracy with zero dripping or foaming.
Material Versatility Handles fluids up to 100,000cP viscosity and particles ≤5mm in diameter via rotating lobes. Hygienic Construction Wetted parts (316L stainless steel/food-grade silicone) comply with GMP/FDA hygienic standards. Smart Control PLC HMI interface enables recipe storage, output statistics, auto-alarm, and quick container changeover.
Energy Efficiency Servo system reduces energy consumption by 30% vs. pneumatic systems, with speeds up to 60 bottles/min (viscosity-dependent). Workflow: Bottle positioning → Material suction → Servo-quantified filling → Nozzle retraction → Conveying to next station.
