A&D Company beam type load cells

Rated force: 1,000 N - 50,000 N
Rated load: 102 kg - 5,000 kg

Stainless steel body is ideal protection from corrosion (IP67) Low profile and lightweight for easy mounting Compact size. For both tension and compression usage Can be used for multi-point weighing

Rated force: 10 kgf - 300 kgf

Features Hermetically sealed with stainless steel bellows protects from water and moisture Stainless steel body is ideal protection from corrosion Compact size and lightweight For both tension and compression usage Dual guided ...

Rated load: 100 kg - 5,000 kg

Features Dual guided cantilever and shear beam design for high accuracy Hermetically sealed for complete protection from water and moisture and for use in harsh environments Temperature compensation maintains both ...

Rated load: 300 kg - 2,000 kg

Constant moment beam and shear beam construction Designed to resist overload damage Moisture protected Tension and compression loading

Rated load: 500 kg - 5,000 kg

Features Low profile and lightweight for easy mounting For both tension and compression usage Moisture proof Can be used for multi-point weighing

Rated force: 1 N - 20 N
Rated load: 102 kg - 2,040 kg

Features Suitable for use in harsh environments where flammable hazardous substances are handled and corrosion resistance is required. Suitable for platform or tank scales. For both tension and compression applications.

Rated load: 30 kg - 600 kg

Flameproof class ExdlBT4 conformed Adjusted for four corners Tension and compression loading Maximum pan sizes are 400 × 400 mm (LCB01), 400 × 600 mm (LCB02) and 600 × 700 mm (LCB06)

Rated load: 300 kg - 1,200 kg

... protection Up to 4 by 6 foot pan up to 1.22 ×1.83 meter (4×6 foot) par Includes summing box Low-cost two load cell system 300 kg, 600 kg and 1.2 t capacities
