HYDRO LEDUC hydraulic motors

Pressure: 400, 450 bar
Rotational speed: 3,600 rpm - 8,800 rpm
Torque: 28 Nm - 1,006 Nm

Hydraulic motors are of bent axis design with a 40° angle, they combine high performance and reduced size envelope. M series piston motors are designed for fixed and mobile applications, ...

Pressure: 400, 450 bar
Rotational speed: 3,400 rpm - 8,800 rpm
Torque: 57 Nm - 1,006 Nm

Hydraulic motors are of bent axis design with a 40° angle, they combine high performance and reduced size envelope. MA series piston motors are designed for fixed and mobile applications, ...

Pressure: 400, 450, 350 bar
Rotational speed: 3,400 rpm - 6,900 rpm
Torque: 154 Nm - 699 Nm

Hydraulic motors are of bent axis design with a 40° angle, they combine high performance and reduced size envelope. MSI motors offer a valid choice for applications with displacement ...

Pressure: 400, 450 bar
Rotational speed: 6,900 rpm
Torque: 0.54 Nm - 700 Nm

Hydraulic motors are of bent axis design with a 40° angle, they combine high performance and reduced size envelope. The MXP/MXA motors can be used in either closed or open loop systems. In ...

Pressure: 280, 300 bar
Rotational speed: 4,000, 4,200 rpm
Displacement: 45 cm³

The MT 45 is an in-line piston motor. Its « semi-integrated » design makes it very compact. Equipped with a conical keyed shaft, it is optimal for mounting on fan drive. On request, the MT 45 motor ...

Pressure: 0 bar - 400 bar
Rotational speed: 3,550 rpm - 6,800 rpm
Displacement: 85 cm³ - 115 cm³

... displacement control, high pressure H2N two speed hydraulic displacement control E2N electric two speed displacement control For other control options, please consult us. As an option, these motors ...

Pressure: 5 bar - 350 bar
Rotational speed: 3,500 rpm - 4,500 rpm
Displacement: 49 cm³

M : Motor. SI : Semi-integrated, model definition already used for the fixed and variable displacement motors, meaning that the flange is further back so the motor can easily be fitted ...

Pressure: 400, 450 bar
Rotational speed: 150 rpm - 3,150 rpm
Torque: 67 Nm - 1,006 Nm

The W/WA pumps have been developed to meet the needs of both the industrial and the mobile hydraulic market. The W series (ISO version) is available in displacements from 5 to 180 cc/rev. The WA series (SAE version) ...
