High-pressure hydraulic motors

Displacement: 28 cm³

... pistons rest directly on the drive shaft where they generate torque depending on the pressure. High power density Very high total efficiency High ...

Pressure: 450 bar
Rotational speed: 3,000 rpm - 5,175 rpm
Torque: 134 Nm - 1,146 Nm

Compact high pressure motor for integration in mechanical gearboxes Size 23 … 180 Nominal pressure up to 450 bar Maximum pressure ...

Pressure: 0 Pa - 35,000,000 Pa
Rotational speed: 0 rpm - 2,300 rpm
Torque: 0 Nm - 6.45 Nm

The sustainable capacity and high pressure make T motors ideal for heavy duty use. The TV-TD motors enable continuous displacement variation. It is possible ...

Pressure: 0 bar - 450 bar
Rotational speed: 0 rpm - 2,200 rpm
Torque: 0.62 Nm - 25.9 Nm

HCD is an High Performance Radial Piston Hydraulic Motor capable to work up to 450 bar in a wide speed range. Its Innovative Swivelling Cylinder System (Patented by Italgroup) grants ...

Pressure: 250 bar
Rotational speed: 3.02 rpm - 40 rpm
Torque: 6,630 Nm - 22,440 Nm

The enhanced variable displacement HPC models include special low friction components, combined with crankcase flushing flow, to achieve increased shaft power. It is used around the world in marine and offshore winch ...

Pressure: 400 bar
Rotational speed: 0 rpm - 2,400 rpm
Torque: 2,149 Nm

These motors are available for both open and closed circuits. The swashplate design enables an optional through drive for further units or, e.g., an external holding brake or service brake.

Pressure: 210 bar
Torque: 865 Nm
Displacement: 80 cm³ - 500 cm³

... applications High brand value and preferred product in EU Disc valving system High efficiency under high pressure Three-zone motor ...

Pressure: 450, 400 bar
Rotational speed: 3,400 rpm - 8,800 rpm
Torque: 66 Nm - 700 Nm

Hydraulic motors are of bent axis design with a 40° angle, they combine high performance and reduced size envelope. The MXP/MXA motors can be used in either closed ...

Pressure: 27,500,000, 21,000,000 Pa
Rotational speed: 1,000 rpm
Torque: 850, 990 Nm

... distribution valve. This orbit motor maintains a high efficiency and outstanding starting performance, even under high pressure conditions. Optional functions Disc ...

Pressure: 300 bar
Rotational speed: 600 rpm - 3,000 rpm
Torque: 0 Nm - 200 Nm

... Displacements from 2.1 to 4.48 cu.in/rev. High volumetric efficiency throughout the full pressure range, by narrow machining tolerance range and by floating plates, that ensure axial compensation. High ...

Pressure: 0 bar - 450 bar
Rotational speed: 0 rpm - 4,160 rpm
Torque: 329, 439, 567 Nm

- High pressure hydraulic motor for hydrostatic transmissions - Low noise level - High efficiency Fixed displacement axial-piston motors ...

Pressure: 155, 172, 34 bar
Rotational speed: 2,400, 3,000, 4,000, 3,600 rpm
Torque: 3.3 Nm - 20.9 Nm

Range of the speed and pressure is from 43.9 to 193.2 cm3/r with 172 bar of maximum pressure and 9 torques. The inner chambers are equally and diametrically opposed which results to balanced radial loads. ...

Pressure: 21, 26, 31 MPa
Rotational speed: 385, 577 rpm
Torque: 540, 665 Nm

... low pressure of start-up, provide smooth and reliable operation and high efficiency. * The output shaft adapts in tapered roller bearings that permit high axial and radial forces. ...

Pressure: 4,500 psi - 5,000 psi
Rotational speed: 0 rpm - 1,100 rpm
Displacement: 197 cm³ - 606 cm³

... increased radial and axial capacity. Larger diameter output shaft. Single stack motor weighs 112 lbs. Double stack motor weighs 149 lbs. 4-port motor weighs 187 lbs.

Pressure: 350 bar - 400 bar

... Axis Piston Motor – MBIF Series • - Higher Pressure • - Compact Design • - High Reliability • - Bidirectional Iron Cast Piston Motor – MBIF series Iron Cast Piston ...
