Three-phase geared motors
Popular geared motors with constant speed and high functionality; power range 0.06 to 45 kW; output torques of up to 9,000 Nm
Detailed information
Geared motors - inverter variable speed drives
Popular industrial geared motors combined with electrical adjustment via 8200 motec frequency inverter; power range 0.25 to 7.5 kW; the distributed drive solution
Detailed information
Geared motors - electronic starter
Popular industrial geared motors combined with the electronic starter starttec; power range 0.25 to 4.0 kW; the distributed drive solution
Detailed information
Geared servo motors
Highly dynamic geared servo motors with synchronous and asynchronous servo motors; max. torque: 7 - 9,000 Nm; low backlash
Detailed information
Gearboxes - with shaft or flange input
Speed reduction gearboxes with free shaft or IEC flange at the input side suitable for motors to IEC 72; output torques of up to 9,000 Nm; finely stepped output speeds
Detailed information
Geared motors - mechanical belt adjustment
Popular industrial geared motors combined with mechanical adjustment via Simplabelt compact units; power range 0.25 to 45.0 kW; adjustment range 1:6
Detailed information
Geared motors - mechanical adjustment Disco
Popular industrial geared motors combined with mechanical adjustment via Disco variable speed drive; power range 0.25 to 7.5 kW; adjustment range 1:6
Detailed information
Disco variable speed drives
Mechanical adjustment with Disco variable speed drive; power range 0.25 to 7.5 kW; adjustment range 1:6
Detailed information
Standard three-phase AC motors
Standard three-phase AC motors; 0.25 to 22.0 kW 3 x 230/400 V; enclosure IP 54; mountings B3, B5 or B14; these motors are optimised for operation with a frequency inverter
|
|
TYPE RT36
Gearbox Specification
Construction Diecast Case + front plate
Drive shaft Stainless steel
Bearings Sintered steel
Gearing Spur and helical gears using steel, brass, tufnol and nylon running on hardened spindles
Temperature 80°C max at the gearcase
|
|
Type
0IK1A-AW2J
Series
Induction motors (1-3 W)
Technical data
Type
0IK1A-AW2J
Frame size [mm]
42
Output power [W]
1
Shaft type
round
Gear ratios [1:x]
no gear
Rated speed for 50 Hz/60Hz [r/min]
1000/1200
Max. permissible torque for 50 Hz/60 Hz [Nm]
0.0095/0.008
Protection class
IP20
Power supply
single-phase 100 VAC
RoHS-compliant
yes
|
|
Type
FPW425A2- J
Series
Watertight motors with IP67 (FPW-Series)
Technical data
Type
FPW425A2- J
Frame size [mm]
83
Output power [W]
25
Gear ratios [1:x]
3, 3.6, 5, 6, 7.5, 9, 12.5, 15, 18, 25, 30, 36, 50, 60, 75, 90, 100, 120, 150, 180
Rated speed for 50 Hz/60Hz [r/min]
500-8.3/600-10
Max. permissible torque for 50 Hz/60 Hz [Nm]
0.5-8/0.41-8
Protection class
IP67
Power supply
single-phase 100 VAC
RoHS-compliant
yes
|
|
Standard type
Gear ratios: 1:3 - 1:200
Max. permissible torque: up to 40Nm
Right-angle type
Gear ratios: 1:3 - 1:150
Max. permissible torque: up to 20Nm
Linear gearheads
Rack length: 100mm - 700mm
Max. permissible thrust force: up to 1400Nm
Feed speed: 10, 25, 45 and 50mm/sec
|
|
|
|
