A full line of cartridge valves composed by a poppet or spool cartridge and by a functional cover that retains the cartridge into properly machined blocks and provides hydraulic piloting.
- pressure control: relief, reducing, compensators
- flow control: with manual setting for fine regulation or with stroke limiter
- directional control: with solenoid valve and optional shuttle valve for pilot selection
- check function: normally open/closed with optional hydraulic pilot operated check valves
- on-off active safety cartridges, hydraulic power shut-off function with optional sensor/microswitch
|
|
Moog's extensive experience in the application of cartridge valve technology enables us to offer a complete product line ranging from size 16 to 160. Sizes 16 to 100 are per DIN standard 24342.
In addition to our standard cartridge valves, Moog also offers a complete line of high flow, active, and servocartridge valves for specialized and higher performance fluid power systems.
Moog has application experience in Metal Forming and Presses Applications.
|
|
Product description
- Complete range of Screw-In Cartridge Valves (SICV) including:
- Directional Controls
- Pressure Controls
- Flow Controls
- Electro-Proportional
- Check Valves
- Load Controls
- Logic Elements
- Multi-Function Valves
- Eaton offering includes components alone, in aluminum or steel housing, or assembled in a Modular Circuit Design (MCD) tailored to customer specific needs
Benefits & Customer Values
- Complete product range that keeps expanding (Stainless Steel, 350 range, -12...)
- Valvelocity Preferred Product Program
- Custom MCD design capability
- Eaton Vickers' brand recognition
- STC direct porting on MCD
Specs
- Size - 8 until - 20
- Rated pressure, 2 ranges: 210 bar/3000psi and 350 bar/5000psi
- Rated flow up to 567 LPM/150 GPM (flow dividers - FDC3-20)
|
|
Types:
Two Way Spool Valves are available in Normally Closed and Normally Open types
Two Position, Three Way Spool Valves
Two Position, Four Way Spool Valves
Three Position, Four Way Spool Valve
|
|
Directional Valves
Pressure Control Valves
Flow Control Valves
Solenoid Valves
|
|
Slip-In Cartridge
6 Sizes for a variety of
Pressure and Flow Applications.
Screw-In Cartridge
5 Sizes for a variety of
Pressure and Flow Applications
|
|
Sauer-Danfoss valves are designed to be flexible, which allows them to meet virtually any need. The modularity of our proportional and directional valves, the variety of our cartridge valves - as well as the flexibility of our electrohydraulic products - allows Sauer-Danfoss valves to be used in applications ranging from road building and construction machinery to agriculture and forestry equipment.
PVG 32 is a hydraulic load-sensing valve designed to give maximum flexibility. It is available in many versions, from a simple load sensing directional valve to an advanced electrically controlled load-independent proportional valve. The module capability of the PVG 32 makes it possible to build up a valve group to precisely meet your requirements. The compact external dimensions of the valve remain unchanged whatever combination is specified.
|
|
When you need finished Integrated Hydraulic Circuits with extremely short lead times, the Parker Speed Shop is the place to go. Parker’s expert application engineers, along with the latest computer-aided design and manufacturing technology, can bring new and advanced custom products to market faster, keeping you way ahead of your competition.
|
|
Flow control valves
MRP / MVR
These cartridge flow control valves provide pressure- independent division of a flow of oil into a constant flow and a surplus flow. Inlet flow maximum 40 l/min.
MTCA
These valves provide pressure-independent division of a flow of oil into a constant flow and a surplus flow. The two part-flows can be pressurized independently of each other. With integral pressure relief function.
MTKA
These valves provide pressure-independent division of a flow of oil into a constant flow and a surplus flow. The surplus flow can be pressurized and can therefore be routed to an additional actuator.
|
|
Typically associated with relatively high flows, slip-in cartridge valves are targeted for efficient, fast and compact hydraulic systems. Eaton cartridge valve system technology meets the changing needs of new generations of hydraulically operated machinery and equipment. Today's machines need controls that are exceptionally cost effective and energy efficient. Vickers cartridge valves fulfill these needs.
Benefits & Customer Values
- Lowered installation costs
- More efficient operation
- Elimination of external leakage
- Greater contamination resistance
- System design flexibility and improved reliability
Size - NG16-100
- Rated pressure up to 350 bar/5000 psi
- Rated flow up to 5000 lpm/1300 GPM
- Function - pressure, direction, flow, and proportional
|
|
characteristics
ports PCD-1 without valve body
PCD-2 without valve body
function NC
pressure range 0-200 (see pressure diagram) bar
Kv value 3,0 m³/h
media gaseous - liquid - highly viscous -
gelatinous - pasty
flow direction A B as marked
switching cycles 700 1/min
switching time ms opening 30-3000 closing 30-3000
media temperature °C direct mounted pilot valve 60
ambient temperature °C direct mounted pilot valve 50
approvals
weight kg PCD-1 1,1 PCD-2 1,2
additional equipment
nominal voltage Un DC 24V
Un AC 230V 50 Hz
power consumption DC 4,8 W
AC pick up 11,0 VA holding 8,5 VA
protection IP 65 (P54) acc. DIN 40 050
energized duty rating ED 100%
|
|
The CV629 is suitable for high cycling automated dispensing applications and can also be used for hand dispensing applications due to its lightweight design. Cartridge valves can be used for silicone dispensing, RTV and silicone oil dispensing, grease dispensing and lubricant dispensing.
Features
• Suitable for all types of materials
• Air and material inlets are aligned for side-by-side mounting of multiple valves
• Stroke adjustment to fine-tune shot size
• Replaceable cartridge seals
• Designed to deliver precise Microshot deposits
|
|
