Cartridge check valve 630 series
Add to favorites
Compare this product
Characteristics
- Type
- cartridge
- DN
Min.: 0.5 in
Max.: 2 in
- Pressure
Min.: 0.5 bar
(7.3 psi)Max.: 10 bar
(145 psi)- Temperature
Min.: -10 °C
(14 °F)Max.: 95 °C
(203 °F)
Description
The alternative to stainless steel made of corrosion-resistant gunmetal. The advantages of an external adjustment possbility during operation, high flow rates at low differential pressures, suitability for liquid and gaseous media. Easy service due to the replacement valve cartridge make this diaphragm-controlled overflow valve suitable for a wide range of applications.
For the protection of:
- pumps against overloading in closed circuits for neutral / non-neutral, non-sticking liquids
For the control of:
- systems under pressure for air, neutral / non-neutral gases and vapours
- test rig construction
- process equipment construction
- de-icing technology
- mechanical engineering
- industrial applications
