VMC VERTICAL SPINDLE
Haas Automation offers a wide range of VMCs - one just right to meet the demands of every machine shop.
The Toolroom Mills combine the power of CNC with the ease of manual control. Haas CNC verticals have travels ranging from 406 x 305 x 254 mm (xyz) on the Mini Mill and Super Mini Mill to 3048 x 1016 x 762 mm on the monstrous VF-11. Workpiece sizes run the gamut, too, with tables available from 305 x 914 mm all the way up to 711 x 3048 mm.
The range of possible applications is as varied as the capacities: 7,5 hp Mini Mill, 15 hp Super Mini Mill, 20 and 30 horsepower motors for the VF line; speeds ranging from 0 to 7500 rpm, with options for 10000, 15000 and 30000 rpm; and torque ratings up to 450 ft-lb. These machines are flexible enough for both high-torque, heavy-duty cutting as well as your finest high-speed machining operations.
The legendary Haas control makes every one of our VMCs easy to operate. With special Haas-only features like word-processor editing, one-button features, multi-function jog handle and Visual Quick Code programming, you'll find the Haas control is the most user-friendly CNC control available anywhere. Operating the machine becomes like driving your favorite sports car: It'll go wherever you point it. It's easy to point. And it won't say no.
|
|
Description
MAKINO's V-series which has been developed especially for the mold construction offers an extensive performance spectrum and a multitude of constructive solutions. These guarantee permanent process stability and accuracy and the best quality surface finish.
The machining centres of the V-series are distinguished in particular by the rigidity and stability of the components, its outstanding damping properties and the uncompromising design of the machine structure. MAKINO sets new standards for the modern mold construction.
Constant developments in technologies are the basis for fulfilling the requirements of the mold construction with the highest quality of production.
|
|
|
The AZ150L rs a high-accuracy and high-efficiency vertical machining center that machines small-sized-parts wrth nano level accuracy, ft is equipped with counter balance axes to eliminate machine vibration. The AZt 50L can perform excellent and high accuracy machining tor both surface finish and profiles.
|
|
|
|
|
|
HS430L
Sodick's high-speed linear machining centre.
As a pioneer in the use of highly dynamic linear drives in machine tools, and based on years of experience with over 10,000 linear EDM machines, Sodick is presenting a new generation of high-speed linear machining centres with linear drives in all axes – the HS L series
High acceleration rates > 1G, maximum stability and the highest degree of precision down to the nano realm are the top attributes of this innovation, which heralds a new era in milling tools. Not least because the handling of the machine is extremely easy and safe, thanks to the Windows-based CNC controller combined with Sodick Motion Control software.
Unlike the conventional method of separately executed rough and fine milling, this new technology combines both these machining passes in the one operating mode. The solution is a rapidly rotating and traversing tool of small diameter that cuts to fine depths.
Fine depth milling
Small diameter cutting tools are ideal for minimising the cusp (residual surface roughness after cutting) and therefore milling resistance. The result is enhanced dimensional accuracy, surface finish, and tool life.
High Speed Milling
High-speed milling shortens cycle times and therefore the whole machining period. Other advantages are improved surface qualities, multi-purpose tools, and minimising chip sizes for ease of disposal. In addition, this technology does not require coolant, so dry (semi-dry) machining is also possible.
|
|
DATRON M8
Versatility
Benefit with DATRON's CNC machining system M8 from our many years of experience in the specially economic and top-quality machining of Aluminium and Plastics!
A large machining area and high precision -
the M8 system completes the range of machining systems offered by DATRON when higher requirements in milling efficiency and precision are on the agenda.
With the know-how of more than one thousand installations world-wide, DATRON will offer you the security and quality of technically-mature production solutions for your machining tasks.
|
|
PHANTOMATIC T3 A
CNC machining centre with three controlled axes, designed for machining operations on bars or workpieces made of aluminium, PVC, light alloys in general and steel up to 3 mm thick. It is provided with a 4-place tool magazine, with provision for containing 2 angle machining heads and a side milling cutter, for machining operations on the 5 faces of the workpiece. It also has a traversing work table which facilitates workpiece loading/unloading as well as considerably increasing the machinable section.
|
|
Description
The S33APC vertical machining center utilizes a 40 taper, 13,000-rpm spindle with the stiffness and rigidity required for hard cutting applications and the speed necessary to provide high surface quality for demanding die and mold applications. Heavy cast construction and an axis configuration with no overhangs ensures high machine rigidity, resulting in outstanding accuracy over the full range of travel. It is capable of maintaining positioning accuracies to within ±.0001 inch (.003 mm) and repeatability of ±.00008 inch (.002 mm).
|
|
R1, the new vertical machining center, equipped with a cross table, is the expression of the Serrmac evolution could reach applying the latest and most advanced technologies, in order to improve the performances of the machine and to satisfy the requirements of a production which has to be particularly effi cient for precision and reliability.
X axis 460 mm-Y axis 370 mm-Z axis 420 mm with a Working surface 600 x 350 mm; Max spindle power 5.5 kW, Max spindle speed 10.000 rpm and Rapid feed 30 m/min.
R1 model is aveileble in two version: Tool storage with nr. 12 tool positions and Wheel tool storage with nr. 16 tool positions, RANDOM type selection and with double-grip.
The control board is installed on the right side of the machine and there
are located all the elements of control: alphanumeric keyboard, CNC 10,4”
video color with graphic to visualize the different machining programs, alarms and machine messages, all the manual controls.
|
|
|
|
|
|
TK 446 - 3-axis CNC vertical machining center.
The flexibility of the TK 446 model makes it particularly suitable both for small manufacturing enterprises that often need to perform several tooling-ups due to frequent production changes and to larger multinational corporations that have to machine large batches.
Thanks to its excellent price/quality ratio, the TK 446 model represents a good starting point for those who wish to abandon their old machines with manual commands and to approach to industrial automation systems and to numeric-control machining centers.
The TK 446 model stands out for the high useful working lengths (also using aggregate heads) that set the TK 446 apart from other machining centers in the equivalent price range; this machining center is designed for drilling and conventional milling processes and also for copy-milling operations on aluminum extruded profiles and other materials, including steel profiles up to 5 mm thick, steel reinforced PVC, and various other plastics or wood.
Standard versions are available in 2 machining lengths: 3500 and 6500 mm.
Axis X: 3500 – 6500 mm
Axis Y: 370 mm / 250 mm (with aggregate heads)
Axis Z: 250 mm / 250 mm (with aggregate heads)
|
|
The advanced machine design of the DMC 35 V series delivers superb quality at an unbeatable price. The series comes standard with the most requested features like a 10,000 rpm motor spindle, 20x-tool magazine with double gripper, high rapid traverse speeds and high-tech controls with 3D-software. With spindle speeds up to 18,000 rpm, high dynamics and excellent sturdiness, the DMC 64 / 104 V linear suitable both for high volume chip removal and machining in the tool and mould sector. The tool magazine with 30 pockets and fast pick-up tool changer for setup parallel to production time lead to minimal idle times and delivers top productivity.
|
|
Bridgeport manufactures a full line of vertical machining centers to meet a broad spectrum of performance, capability and budget requirements. Our "best-in-class" design means you'll successfully make all of your parts right every time, year after year. You can count on Bridgeport machines to perform accurately over time, whether you're buying our performance series or our high performance vertical machining centers.
XR Series - High Performance (X,Y,Z)
P3 Series - Performance (X,Y,Z)
GX-Series - Performance (X,Y,Z)
XV Series - Standard (X,Y,Z)
|
|
Chip auger or optional conveyor for chip removal
Huge fully ground machine table with 5 T-Slots
Automatic lubrication
Spindle cartridge cooling system
35HP closed loop spindle motor with two-speed gearbox
AC Yaskawa Digital Servos
110mm O.D. 5 bearing spindle with air-purge seal
Inverted rail design in X axis means table support is always centered under the spindle
1000 IPM rapid traverse
Fully ground double anchored ballscrews
High speed Centurion PC based conversational control
Networking capable
|
|
Rigid Meehanite casting, Heavy square (box) ways design on all axis, Four slide way design on base, Hardened & Ground square (box) ways on all axis, High precision C3 class ball-screw, Per-tension ball-screw design on all axis, All axis direct drive design, 8000rpm spindle speed.
Table size 930x460mm (36.5"x18")
Table T-slot (WxN) 18mm (0.71")x4
Max. table load (Center) 400kgs (880lbs)
X travel 860mm (34")
Y travel 510mm (20")
Z travel 610mm (24")
|
|
Rigid Meehanite casting, Heavy square (box) ways design on all axis, Four slide way design on base, Hardened & Ground square (box) ways on all axis, High precision C3 class ball-screw, Per-tension ball-screw design on all axis, All axis direct drive design, 8000rpm spindle speed.
Table size 830x405mm (32.6"x16")
Table T-slot (WxN) (32.6"x16")
Max. table load (Center) 350kgs (770lbs)
X travel 660mm (26")
Y travel 510mm (20")
Z travel 610mm (24")
|
|
Rigid Meehanite casting, Heavy square (box) ways design on all axis, Four slide way design on base, Hardened & Ground square (box) ways on all axis, High precision C3 class ball-screw, Per-tension ball-screw design on all axis, All axis direct drive design, 8000rpm spindle speed.
Table size 770x330mm (30"x12")
Table T-slot (WxN) 16mm (0.63")x3
Max. table load (Center) 200kgs (440lbs)
X travel 450mm (18")
Y travel 350mm (14")
Z travel 460mm (18.1")
|
|
Features :
- Frame design using finite element analysis
- 24-station, swing-arm automatic tool changer
- 8000 rpm belt driven spindle design with coolant ring
- Heavy-duty ball-type linear guideways in all three axes
- Large-size pre-tensioned ball screws
- Servo-driven Z-axis travel for smooth contour machining without mechanical counterweights
- Robust control software and user-friendly, ergonomic control panel
- Dual-linked front doors for easy access
- Rigid tapping
- Artificial intelligence with contour control
|
|
|
|
|
|
TK 428 - 3-axis CNC vertical machining center.
Structure robustness and high stability of all components of this machining center allow the TK 428 model to be used not only to perform machining operations on light alloys and similar materials but also on materials that require higher performances (i.e. steel, iron, etc.). The peculiarities of the machine assure an excellent superficial finishing and a better machining accuracy.
This machining center is designed for drilling and conventional milling processes and also for copy-milling operations on aluminum extruded profiles and other materials, including steel profiles up to 10 mm thick, steel reinforced PVC, and various other plastics or wood.
Standard versions are available in 3 machining lengths: 3500, 6500 and 8000 mm. Upon request the machining center can be manufactured in different lengths in order to meet the special needs of each customer.
Over the years TEKNA has produced various versions of the TK 428 model customizing it in order to machine composite and sectional panels. TEKNA has designed several systems for clamping, for automatic loading/unloading processes, for the moving of profiles as well as dust suction systems.
|
|
|
|
|
|
TK 429V - 3-axis CNC vertical machining center with superior machining capability in Y (2000 mm). It features a clamping system made up of vacuum tables that allow panels and plates to be held by vacuum; this solution is useful to obtain an extremely efficient machining of thin components that could hardly be fixed by means of a traditional clamping system.
The TK 429V is equipped with a series of valves that turn on/off different areas of the machining table, thus concentrating the suction on one area and optimizing the clamping of components with limited dimensions.
This machining center is designed for drilling and interpolated milling operations on composite panels, panels and plates in aluminum, stainless steel, titanium and on aluminum profiles.
Standard versions are available in 3 machining lengths: 4000, 6500 and 8200 mm. Upon request the machining center can be manufactured in different lengths in order to meet the special needs of each customer.
The two longer versions of this model can be used in the TWIN mode that allows to divide the machining area into two distinct areas thus reducing the idle time due to loading/unloading operations.
It is available also in the TK 429VF version that is equipped with 4 machining axes.
|
|
CFV 1050
MAG Cincinnati's new generation of CFV (Cast Frame Vertical) machining centers enable you to produce more parts, more accurately and more profitably. Constructed for rigidity, power and efficiency, the CFV platform delivers smoother finishes, shorter programming and set-up times and new possibilities to increase your bottom line.
The CFV 1050 offers a wider table making it ideal for large molds and deeper parts.
|
|
|
|
|
|
TK 429 P - 3-axis CNC vertical machining center.
Specifically designed to manufacture sectional panels, this model is equipped with a clamping system that can be rapidly adjusted to the width of the loaded panel, in order to fix panels with different widths without modifying the tooling-up of the machine. It features a fixed bar and a mobile bar that shifts along the Y axis and performs the clamping operation through pneumatic pistons.
Rollers mounted under the machining table ease the movement, allowing the simple loading/unloading of panels and the removal of chips.
This machining center is designed for drilling and conventional milling processes and also for copy-milling operations on aluminum and steel sectional profiles, for industrial heavy doors and garage doors and for sandwich panels with polyurethane foam cores for walls and coatings, etc.
In order to simplify the machining process, TEKNA has developed a software for the manufacturing of industrial doors, that is able to automatically create programs.
|
|
Description
MAKINO's V-series which has been developed especially for the mold construction offers an extensive performance spectrum and a multitude of constructive solutions. These guarantee permanent process stability and accuracy and the best quality surface finish.
The machining centres of the V-series are distinguished in particular by the rigidity and stability of the components, its outstanding damping properties and the uncompromising design of the machine structure. MAKINO sets new standards for the modern mold construction.
Constant developments in technologies are the basis for fulfilling the requirements of the mold construction with the highest quality of production.
|
|
|
|
|
|
480 Series
Machining centers that offer a range of productivity and performance enhancing features, including an automatic rotary pallet changer. Our Vertical Pallet changers are extremely suitable for a diverse range of jobs and machining applications designed to increase your productivity...fast!
700 Series
Bridgeport Machines new generation Automatic Pallet Changing Vertical Machining Center is a fully digital, high quality machine tool, designed to achieve maximum capacity and performance in the Aerospace, Mould & Die, Telecommunication Industries and many other manufacturing sectors. This machine has been developed to provide a powerful and precise solution to meet the demands of the metal cutting user.
XR 1000 APC
The XR 1000 APC was designed to increase your productivity...fast. As well as having built-in automation via 2-station APC capability and 32-position ATC, the machine also is equipped with a number of performance enhancing features that are fitted as standard-i.e. swarf management system, chip conveyor, chip augers, coolant wash gun and spindle oil chiller.
|
|
|
M2 ROTOPALLET the versatility of the machine structure of the series M made possible SERRTECH the realization of the M2, a vertical processing center “Rotopallet”. This model with pallet change-over switch is a machine, which is aligned to customers, who need high speeds as well as high accuracies, reliability and the reduction and of the unloading times with the machine cutting. A goal of SERRTECH was it to build machines which make an optimal service as well as maintenance work possible.
|
|
DATRON M10 Power
The most powerful HSC machining system from DATRON!
The DATRON M10 Power machining system combines productivity, flexibility of use and a large work area and requires little floor space. With a high manufacturing quality and low costs per piece, this machine will put you a significant step ahead of your competitors.
|
|
CFV 1300
MAG Cincinnati's new generation of CFV (Cast Frame Vertical) machining centers enable you to produce more parts, more accurately and more profitably. Constructed for rigidity, power and efficiency, the CFV platform delivers smoother finishes, shorter programming and set-up times and new possibilities to increase your bottom line.
The CFV 1300 is the largest machine in the CFV family, making it ideal for the machining of long parts to take advantage of its 1370 mm long worktable. It is also great for multiple setups to increase profitability.
|
|
The entry level machine (XR 1500) has a 10,000rpm, 30kW (40.2hp) 40 taper SKF belt-driven spindle. Faster spindle speeds are available on the more advanced (XR 1500 HP) model which provides users with 15,000rpm from its 30kW (40.2hp) 40 taper SKF directly-driven spindle. And the last model in the range is the XR 1500 HPD - a real powerhouse of a machine - that comes with a ZF two-speed gearbox and achieves 7,500rpm and 764Nm torque (557ft-lb)from its 30kW (40.2hp) 50 taper SKF belt-driven spindle. All spindles are specified with face and taper capability.
|
|
M5 - LINEAR DRIVE , It's a new VERTICAL MACHINING CENTER TRAVELLING COLUMN with linear motor Fanuc on X axe.
This machine can be used also in pendular configuration permitting maximum capabilities as well as a X axis travel of 875 mm on both working area.
Moreover, the ‘M5’ machine is equipped with two indipendent tool storages having 30 tools capacity everyone.
X axis travel 2.200mm
Y axis travel 600 mm
Z axis travel 640 mm
Table Working surface 2400x600 mm
Max loading capacity 6000Kg
Electro-spindle speed 12000 rpm (15000-24000 opt)
Max electro-spindle power for 30 min/continuous 35 - 22.5 kW
Max electro-spindle torque 120 Nm
Axes characteristcs Rapid feedrate (x-y-z) 60 m/min
Work feedrate (x-y-z) 60 m/min *
|
|
DATRON M8 XL - 1600
Large-Format
Machining System
The machining system M8 XL-1500 is specially designed for the precise machining of large-format workpieces. The useable traverse path is 1,020 mm x 1,500 mm with a floor space of 1,850 mm x 2,400 x 1,950 mm. The solid vibration-damped construction with precision linear guides is the basis for high production quality, even whilst machining at high speed. The large swing doors at the front and rear side of the machine enable easy loading of the machine.
|
|
DATRON M7
The new DATRON machining system M7 will substantially increase your machining speed and quality. With a floor space of only 1300 mm x 1300 mm this compact machine offers a traverse path of 520 mm x 650 mm x 240 mm. The solid Granite construction ensures very dynamic CNC milling and at the same time high surface quality. Robust high-torque machining spindles or precisions spindles up to 60.000 rpm are available, tailored to your application requirements. With this compact and low-priced “power house” the precise ma-
chining of Aluminium and Plastics in 2D or 3D can now be carried out much more effectively and economically.
|
|
CFV 550
MAG Cincinnati's new generation of CFV (Cast Frame Vertical) machining centers enable you to produce more parts, more accurately and more profitably. Constructed for rigidity, power and efficiency, the CFV platform delivers smoother finishes, shorter programming and set-up times and new possibilities to increase your bottom line.
The CFV 550 offers high precision machining in a very compact footprint, ideal for small parts or small set-ups.
|
|
|
|
