The AccuStream abrasive waterjet cutting head is the industry leading design. All components are designed and manufactured with exceptionally close tolerances to ensure perfect alignment. The key to the success of the head is the alignment insert. The insert effectively acts as the entire waterjet cutting head, aligning the waterjet stream to the nozzles and feeding abrasive into the cutting stream at the optimal angle. Incoming abrasive is directed in-line with the stream to the top of the abrasive nozzle. Turbulence inside the head is minimized, eliminating the need for mixing chambers and extending orifice life.
|
|
|
The Tilt-A-Jet® represents the latest OMAX® innovation in the continuing search for more accurate abrasivejet machining. The Tilt-A-Jet lets the OMAX® JetMachining® Center achieve virtually zero taper with most materials. The Tilt-A-Jet can position the nozzle at an angle calculated by the software to exactly offset the taper from the abrasivejet. Taper doesn't disappear--it just gets moved to the scrap part of the material, leaving your part with exactly square edges.
|
|
Designed for use with the
OMAX JetMachining
system, the MAXJET 5
is the industry's premier
abrasivejet nozzle for
precision machining
applications.
Durable and accurate
the MAXJET 5 features
an orifice with a robust
design that prevents
abrasive particles from
traveling upstream.
The resulting high-density
jet is tightly defined to
produce a small kerf with
minimal frosting, surface
striations, and taper.
Coupled with OMAX's
patented motion control
software, the MAXJET 5
offers repeatable cut
quality superior to any
other nozzle on the
market.
|
|
|
|
|
|
The industry's premier mini-abrasivejet nozzle
The OMAX MAXJET™ 5 MiniJet Nozzle is designed for abrasive waterjet cutting applications requiring the narrowest possible cut width and/or the most precise possible cut.
It is ideal for making parts with intricate shapes or where minimum possible taper is desired.
The OMAX MiniJet Nozzle is also well-suited to cutting thin delicate material.
Cuts intricate delicate parts with no distortion
Cuts parts with minimum taper from top to bottom of cut to provide the highest possible precision
Cuts minimum-radius inside corners
Narrow cut means less wasted material, so it is ideal for precious metals and exotics
Low hourly operating cost due to low consumption rates of water, abrasive and power
Narrow width of cut (between 0.020" and 0.025")
Extremely coherent jet produces a cut with minimum taper
Very low cutting forces for working on thin delicate material, but still suitable for thicker parts and traditional metals
Interchangeable with a standard OMAX MAXJET 5™ nozzle so it can be installed on any OMAX system with standard OMAX controller and with a variable pressure pump in just minutes.
Low consumption of water, abrasive and power
|
|
Waterjet Cutting Head
ACTIVE IDE PRO
Specially designed for waterjet cutting with up to 6200 bar. As the cutting head contains only a small number of individual components, it is particularly easy to handle and produces high-precision cuts. The key features of the ACTIVE IDE PRO are the precisely aligned cutting jet and the pre-filter protecting the orifice. The unit is also virtually maintenance-free. To achieve a perfect cutting jet, all you need to do is exchange the focussing tube.
|
|
|
The DiaLine abrasive cutting head adapts to all major manufacturers on/off valves and produces more precise parts at considerably higher cutting speeds than parts cut with conventional waterjet heads. The embedded diamond eliminates misalignment and wear caused by damaged ruby orifices. The result is improved edge quality and cutting speeds. Abrasive nozzle life increases by as much as 20%.
|
|
Abrasive Waterjet Cutting Head
ACTIVE AUTOLINE II
For cutting applications with up to 4137 bar. The modular design of the ACTIVE AUTOLINE™ II allows for fast tool-free replacement of the main wear parts such as the orifice including the mixing chamber and the focussing tube. Precise automatic cutting jet positioning, high cutting speeds and perfect cutting edge quality are the main features of this tried and tested cutting head.
|
|
The Resato cutting head type VJW is suitable for cutting with pure or for cutting with water and abrasive. The abrasive cutting head has a Long Life mixing chamber with only two wearing parts: the water nozzle and the mixing tube. The cutting head is pre-aligned. The water nozzle and the mixing tube can be replaced in a very short time without use of special tools. Thus standstill periods for the required replacement of wearing parts in the cutting head can be reduced to a minimum. Conversion to / from pure water cutting can be done rapidly.
To complement our range of cutting heads we offer all waterjet cutting accessories vital to the realization of a turn-key cutting system
|
|
Features:
- Ballscrews & Closed Loop Servos on all progammable axes
- Electronically Geared Servos prevent Gantry skew
- Fully stressed relieved, Ground steel structure Chassis
- Micron accuracy, Precision Guide Rails with 4-point ball contact for rigidity
- Neoprene/Hypalon waycovers on all axes
- PC Based Controller designed for WaterJets
- NEMA 12 Enclosure with Air Conditioner
- CAD/CAM Software
- Precision Abrasive Delivery with Display
- Rich Software
- Hand Held Pendant
- Control - 2 1/2 Axes
- Work Envelope - 5x10 or 6x12 feet
- Accuracy +/-0.005 in
- Repeatability +/-0.001 in
- Rapid Traverse - 200 ipm
- Cutting Pressure - 60,000 PSI
- Stainless Steel Sheetmetal
- High Load Cutting Bed
- Reinforced Steel Tank to absorb Kinetic energy of waterjet stream
|
|
| ... products without technical information |
| |
All Laser Mech cutting heads come with the following features and benefits:
* Magnetic Crash Protection – Eliminates breakaway screws and reduces downtime after a crash to a few minutes
* Easy-Access Lens Drawer(s) – Makes lens replacement, cleaning, and beam centering quick and easy
* Manual Focus Adjustment – Over ¾ of an inch of focus adjustment reduces setup time
* Fixed Tip Assembly – Never have to center the tip again
STATIC SENSOR HEADS FURTHER UPGRADABLE TO NON-CONTACT
The addition of Laser Mechanisms' Height Sensing Unit (HSU) will allow you to remove the foot follower (as needed) and will enable your laser to cut sheet metal non-contact. Here are just some of the benefits:
* Fully integrates with the Mazak controls (L32, L-Plus and L32B)
* Switch between non-contact and contact cutting in minutes
* Reduces the footprint allowing for tighter nesting of parts – reducing scrap considerably
* Non-Contact cutting does not scratch the workpiece
|
|
All Laser Mech cutting heads come with the following features and benefits:
* Magnetic Crash Protection – Eliminates breakaway screws and reduces downtime after a crash to a few minutes
* Easy-Access Lens Drawers – Makes lens replacement, cleaning, and beam centering quick and easy
* Manual Focus Adjustment – Over ¾ of an inch of focus adjustment reduces setup time considerably
* Fixed Tip Assembly – Never have to center the tip again
NON-CONTACT HEIGHT SENSING OPTION (For HC and HD Lasers)
The addition of Laser Mechanisms' Height Sensing Unit (HSU) will allow you to remove the foot follower (as needed) and will enable your laser to cut sheet metal non-contact. Here are just some of the benefits:
* Fully integrates with the Mitsubishi controls
* Switch between non-contact and contact cutting in minutes
* Reduces the footprint allowing for tighter nesting of parts – reducing scrap considerably
* Non-Contact cutting does not scratch the workpiece
|
|
|
|
|
|
Cutting System YRC
3D cutting with fibre optical coupled lasers
Applications:
o 3D cutting
o robot
o multiple linear drive laser equipment
o cutting of thin metal sheets
o cutting of metals
System types/Lasers:
o for all solid-state lasers like Nd:YAG, disc, fibre optical and diode lasers
Features:
o complete system consisting of linear drive, cutting system, controller and collimation unit
o integrated, non-contact, patented distance sensors
o error signals if collision or cable breakage occurs or if measuring area tolerances are exceeded
o symmetrical design
o easy access to all connections (top)
o integrated collision detection
o water cooling system for optical components and fibre sockets
o all water-conducting parts made of stainless steel
o integrated collimation unit
Technical Specifications:
o max. laser power: 4 kW
o electronics: Lasermatic® Z
o focal lengths focusing: 73 mm, 100 mm
o focal lengths collimation: 73 mm, 100 mm
o max. clear aperture: 26 mm
o axial lengths: 350 mm / 380 mm
o dimensions (W x H): 163 x 132 mm
o mass of complete system: about 5 kg
|
|
Our CL-830 laser which is modified slightly for use in the stone cutting industry with added lens protection and a robust power supply it is made to stand up to the rigors of stone cutting.
The CL-830-B comes with the CE-HPS-800 bar mount bracket for easy mounting and a power supply that will work with either 110V or 220V. For flat mounting situations you can use our standard CE-305 bracket.
|
|
The vast experience of El.En. in design and manufacturing of scanning heads equipped with galvanometric driven mirrors allow the realization of marking, cutting, welding and surface treatment systems with extremely high dynamic performances.
The offer of such systems covers from very high speed labeling and packaging systems to high resolution systems for very large working areas.
|
|
|
|
|
|
StarCut®
The new StarCut Generation stands for high quality and speed of cut in a compact form at attractive prices. The whole family is modular, and comprises technologically high-quality components.
The power supply with IGBT switches ensure pulse frequencies of up to 4000 Hz, and a unique pulse-to-pulse stability. The CAN-bus based controller guarantees safety and flexibility for all present and future applications. These include pulse increments of 10 µs, dynamic power control, and on-line trouble shooting.
The laser resonator, based on the proven StarMark rail concept provides high laser power with optimal brilliance of beam. Depending on the application, TEM00, TEM10, TEM20 or fiber-coupled, low-order-mode beam profiles are used. The fast shutter, with a switching time of less than 10 ms, permits holes to be cut in an economically attractive time.
In many areas, the StarCut series provides uniquely high qualities of cut. With approx. 200 installations in the areas of electronics, medical technology, and electromechanics, it has already set a standard for the industry.
|
|
Cutting Head HP1.5"
With integrated non-contact distance control
For high pressure cutting applications
Cartridge replacement system enables faster change of focal length
Preadjustable focusing optics
Water cooled connector head
All connections in the upper part
All water guiding parts are made of highly corrosion-resistant stainless steel
Error signals in case of collision, cable breakage and exceeding the measuring range
Focal lengths: 3.75", 5", 7.5", 10"
Lens diameter: 1.5"
Free aperture: 33 mm
Axial length (f = 5"): 236.4 mm
Max. cutting gas pressure: 25 bar, 365 psi
Nozzle standoff distance: recommended: 1.0 mm to 5.0 mm, possible: 0.3 mm to 10.0 mm
Measuring resolution: < 0.01 mm
Mass (f = 5"): 4.0 kg
|
|
Cutting head YR30
With integrated non-contact distance control
Electrically monitored breakaway
Small measuring spot
Preadjustable focusing optics
All water guiding parts are made of highly corrosion-rsistant stainless steel
Error signals in case of collision, cable breakage and exceeding the measuring range
Focal length: 73 mm
Lens diameter: 30 mm
Free aperture: 27 mm
Axial length: 120 mm
Max. cutting gas pressure: 20 bar, 290 psi
Nozzle standoff distance: recommended: 1.0 mm, possible: 0.3 mm to 10.0 mm
Measuring resolution: <0.01 mm
Mass : 1.1 kg
|
|
| ... products without technical information |
| |
TK 145/10 PLUS Exceptional double mitre saw.
New version of the TK 145/10 model completed with 600mm diameter circular blades that increase its cutting capacity. It offers exclusive performances thanks to its ability of working on multiple angles, thus obtaining a high precision level while ensuring robustness and reliability.
Special fabricated and welded steel bed frame with finish machined,
complete with slideways for the mobile head.
Automatic descent of fully safety protections.
Head tilting from 22° 30’ to 90°.
Accuracy: ± 0,1 mm.
Blade motor power: 2 x 3 kW
Blade motor revolutions: 2800 rpm
Blade diameter: 600 mm
|
|
TWIN ELECTRA SUN
Twin-head cutting-off machine with 3 controlled axes, automatic traverse of the moving cutting head and electronic control of every angular setting from 45° (internal) to 22°30’ (external) with accuracy of 240 places on each degree.
|
|
|
|
|
|
TK 145/20 CNC gold Exceptional double mitre saw.
Full protection with complete cover and front automatic lowering closure.
Special fabricated and welded steel bed frame with finish machined,
complete with slideways for the mobile head.
Double head tilting from 22°30’ / 90° / -45° operated by direct current
motors controlled by NC.
Noise deadening guaranteed by the complete enclosure and also
by acoustic insulation panels
Mobile head operated by direct current motors and controlled by NC.
Travelling speed: 24m/1’
Conveyor belt for chips removal
STANDARD PROGRAMS
- Single cuts
- Sequence of cuts
- Profile codes and profile heights stored in memory for automatically calculating cuts at 45°
- Loading of cutting lists originated from ABACUS/TEKNA program
- Wings cut
- Blade motor timeout: blade motor automatically turns off after an inactivity period of the machine
- Sequence of cuttings on bar: bar manual progress, variable cutting length, possibility to vary the cutting angle on any degree.
- Automatic motor start in manual cuts
- Possibility to work with inches
OPTIONAL PROGRAMS
- Extra-short cut - Extra-long cut
- Automatic in-sequence cuts
- Trimming
|
|
As the leading manufacturer of machines for processing aluminium and PVC profiles, we supply matured solutions for different applications.
You have profile - we cut it !
Further saws, like Table saws, Mitre saws, Double mitre saws, Notching saws, Vee-notch and cut off saws, Automatic saws and Automatic saws with pusher cover our product range.
|
|
|
Twin-blade mitre saw for notching board and panel corners. Equipped with two independent mobile fences for both square- and rectangular-section cuts. A vertical pneumatic clamp assures grip of the panel or the panel stack.
|
|
Item No. : DET-4SA & DET-4SAT & DET-6P
Product Name : Double End Miter Saw
MODEL: DET-4SA
CAPACITY
CARRIAGE Single rail
MAX. LENGTH OF CUT 48"
MIN. LENGTH OF CUT 12"
MAX. WIDTH OF CUT 24"
MAX. CLAMPING THICKNESS 4-½"
SAW
SAWBLADE DIA. 8"/10"/12"(optional)
SAW ARBOR Φ1"
SAWBLADE SPEED 3400rpm
SAWHEAD SWIVEL 360°
MODEL: DET-4SA-T
CAPACITY
CARRIAGE Single rail
MAX. LENGTH OF CUT 48"
MIN. LENGTH OF CUT 12"
MAX. WIDTH OF CUT 24"
MAX. CLAMPING THICKNESS 4-½"
SAW
SAWBLADE DIA. 8"/10"/12"(optional)
SAW ARBOR Φ1"
SAWBLADE SPEED 3400rpm
SAWHEAD SWIVEL 360°
MODEL: DET-6P
CAPACITY
MAX. LENGTH OF CUT 72"
MIN. LENGTH OF CUT 12"
MAX. WIDTH OF CUT 24"
MAX. CLAMPING THICKNESS 4-½"
SAW
SAWBLADE DIA. 8"/10"/12"(optional)
SAW ARBOR Φ1"
SAWBLADE SPEED 3400rpm
SAWHEAD SWIVEL 360°
|
|
Haffner technology :
- Profile table out of steel.
- Strong cast metal construction of sawhead.
- Big cutting capacity - 2 profiles can be cut simultaneously.
- Eeasy positioning by means of roller supported carriage.
- Double supported tilting device.
- Safe from clamping by 2-pressures sytem.
- Double supported saw feeding device.
- Cutting lengths 3,4 or 5,1 m.
- Hydropneumatic saw feed.
- Correction scale for outside dimensions.
- Left aggregate fixed.
|
|
| ... products without technical information |
| |
Landis Thread and Form Rolling program includes:
Thread rolling heads, rolls, consumables and spares
Machine rolls
Replacement rolls - all makes
Along with our range of standard items shown on our site, we can produce a number of special products for your application.
|
|
|
|
