Function : Pressure, air velocity and air flow with Pitot tube
- Manual self calibration
- Adjustable climatic parameters for air velocity compensation
Measuring ranges :
> MP 100 - MP 120 : from 0 to ±1000 Pa
> MP 101 : from 0 to ±1000 mH2O
> MP 105 : from 0 to ±500 mbar
> MP112 : from 0 to 2000 mbar
Supplied with calibration certificate. |
|
Serie 2000 portable handheld digital pressure gauges manufacturer:
Für precise measurement of pressure, vacuum and differential pressure.
Ranges 0/25 mbar, 0/130 mbar, 0/500 mbar, 0/1 bar, 0/2 bar, 0/7 bar, 0/10 bar and 0/2 bar absolute.
Accuracy 0.15% of reading +0.15% of full scale value +1 digit.
Easy operation, great performance, rigid housing IP 67, overrange protection, autoranging professional displays for precise readings, selectable auto switch-off.
Three versions are available:
Basic version, extended version with Min/Max storage and selectable pressure unit and version with data logging and leak testing functions.
Zeroing simply by pressing one key. |
|
Your Compact Vacuum Meters for 1600 to 5 x 10-4 mbar
Compact vacuum meters of the VD8 family are fully electronic and combine high quality sensors and modern microcontroller technology with a handy design.
Our customers appreciate these easy-to-operate gauges as reliable tools in plant engineering, service and laboratory.
The digital display of your vacuum meter shows the exact absolute pressure. Sensors with temperature compensation and sophisticated evaluation electronics guarantee precise and reproducible measurement results.
Optionally the vacuum meters can be used as datalogger in
order to store pressure data during the measurement. By push of a button those data are easily transmitted to a PC where they can be analysed and documented for your quality assurance using our VacuGraph Windows software.
Mobile use or fixed installation? Integrated or detachable sensor? Quick spot check of actual pressure or documentation of measurements on PC? The VD8 will always be in compliance with your wishes.
Further Advantages
- Display of minimum and maximum pressure
- Automatic switch-off or continuous operation
- High battery lifetime due to clocked measurement
- Operation with battery or mains adapter
- Robust stainless steel flange |
|
- 30psi
- Rugged Extruded Aluminum Housing
- Measure positive and differential pressure.
- Push button zero for altitude correction.
- Seven selectable units of measure to choosefrom: mmHg, inHg, kPa,
- Easy-to-read LCD.
- Backlight with auto shut off after 10 seconds.
- Auto shut off after 30 minutes (except RECmode) to save battery life.
- Data hold to freeze reading on LCD. |
|
Digital handheld pressure gauge manufacturer HM 35
For measurements in the area of relative, differential or absolute pressure
Data Memory for 10.000 measurements
Versatile range of applications
Compact and easy to operate
Measuring media: instrument air, inert gases, media compatible with stainless steel 18/8
22 selectable measurement units
Large, well readable graphics display
Infrared interface (IR)
Measurement for leak rate
MIN./MAX. and average values
Real time clock including date
Incl. free of charge SCS certificate
|
|
The Ashcroft® Digigauge® Family brings industry leading features to the marketplace.
The award-winning Ashcroft® digital test gauge features unmatched accuracy specifications of .05% Terminal Point, Total Error Band full-scale including span, linearity, hysteresis and temperature from 0 degrees to 1500 degrees F.
The new Ashcroft Type 2089 digital gauge comes in the industry’s smallest case size of (3") yet has the largest display – larger than even competitors' 4" gauges. The display offers backlighting with adjustable contrast levels. This gauge features 12 selectable engineering units, seven languages, and it can be calibrated in the field. Calibration and dampen modes are password protected. Three AAA Alkaline professional batteries provide over 1000 hours of battery life. The gauge is CE approved and FM approved for intrinsically safe operations, Class1, Division 1.
The Ashcroft® Type 2274 industrial digital gauge has the breakthrough features of 4-20 mA output, switching capability, and an extra large digital display. It is available in three case types.
The general purpose digital gauge, Type D1005PS, has 1/2% full-scale terminal point accuracy, large 1/2 inch character size and brings standard features to the digital gauge market that, until now, were either not offered or were provided only as options on competitor's products.
|
|
Alicat Scientific's line of P Series Digital Pressure gauges supplier are a group of indicating professional transmitters that digitally display pressure as well as offer a variety of output options. Signal outputs include 0-5Vdc, 0-10Vdc, 4-20mA, or RS-232. Units range from 0-30PSIA and 0-250PSIG in gas and liquid. Add to that the optional battery pack and dynamic digital display, and you have a versatile high precision calibration and testing device designed for rugged field use.
Common Applications for Alicat Pressure Gauges
• Laboratory
• Leak checking
• Equipment operation verification
Benefits to Alicat Pressure Gauge
• Accuracy +/- 0.5% of Full Scale
• -10 - +50 C Temp range
• 200:1 Turndown Ratio
• Repeatability +/- 0.1% of Full Scale
Now with an industry first, lifetime warranty! |
|
One M1 digital suppliers of pressure gauge can replace three or more mechanical gauges
Unlike Mechanical Gauges:
- Dropping can’t affect accuracy. The housing and professional boot are compatible with many industrial fluids including Skydrol®
- Overpressure doesn’t affect accuracy
- Repeatable readings
- No temperature or gravity effect
Unlike Other Digital Gauges:
- More resolution
- Shock mounted electronics
- Protected LCD
- Uniform backlight
- Very easy to use, no manuals, no menus, no problem!
Unlike Anything Else:
- 0.2% of reading! Like a deadweight professional tester!
- Calibration report with data at five temperature
- Replace three or more 0.25% standard gauges
- CE certified and manufactured under a ISO 9001 registered quality system
- Runs on 2 AA alkaline professional batteries providing up to 30,000 hours of service
- Precision and performance at an affordable price
Pressure is Our Business!
|
|
Battery operated digital reference supplier of pressure gauges:
Type TLDMM: Accuracy ±0.05% f.s.
Type TLDMM-A01: Accuracy ±0.1% f.s.
Type TLDMM-A02: Accuracy ±0.2% f.s.
Type LDM 70-E25: Accuracy ±0.25% f.s.
Type LDM 70-K50: Accuracy ±0.5% f.s.
A lot of different pressure ranges between 0/100 mbar and 0/2000 bar available.
The pressure unit is switchable to psi, MPa, and other units.
Robust contruction, wetted parts in stainless steel.
Precise measurement of pressure and pressure peaks.
Optional with RS232-interface (TLDMM-types)
Optional in build-in case for panel mounting (TLDMM-types).
Pressure port: 1/2" BSP male, stainless steel |
|
"The surveillance of the working pressure in a system is a very important operation parameter in fluid power and lubrication systems.
Depending on the type or mode of the control system, the display and / or the indication of relevant pressure levels, different pressure limits or continuous readings are required. In many cases a variety of different sample points are controlled and displayed by pressure gages with professional digital displays at a centre point. Traditionally, these pressure switches are all hydraulically piped up to the sample points.
The Pressotronic now offers a more contemporary and simple method for reliable surveillance of system pressure.
Depending on the application we offer a choice of adjustable pressure switches with digital display directly installed at the sample point or versions with separate sample point professional transmitters and professional remote control and display units. In this case, the transmitter and the professional displays are connected just by simple elastic cables instead of inflexible industrial pipes.
Both versions provide almost fully identical modules. The control and display unit features a three digit Light emitting diode display with good readability even under poor visibility conditions. As a combined unit, the display can be positioned within an angle of 270° .
The control unit itself is designed for 35 mm rail mount. This allows to compile several units without additional installation materiel in professional cabinets.
The transmitter is available for stand alone with an analogue 4-20 mA output. |
|
Unlike Mechanical Gauges:
- Dropping can’t affect accuracy
- Overpressure doesn’t affect accuracy
- Repeatable readings
- No hysteresis
- No temperature or gravity effect.
Unlike Other Digital Gauges:
- More resolution
- very rugged water resistant case is gasketed per NEMA4 and IP66
- backlit display
- available with optional dual line pressure display to view peak and live pressure simultaneously - ideal for relief cock testing
- easy to use buttons
- intrinsically safe
- 5 full digits – great for leak testing
- can be calibrated via the keypad or the RS232 port or automatically using a calibration grade pressure controller
Unlike Anything Else:
- 0.1% of reading! Like a deadweight professional tester!
- Calibration report with data at five temperature
- Replace three or more 0.25% standard gauges
- Intrinsically safe (ATEX) pressure industrial recorder option
- Pressure recording by DataLoggerXP to record pressure and ConFigXP to enable or disable features
- Customize your XP2i for panel mounted configurations or portable applications
- any XP2i can be cleaned for oxygen service
- CE certified and manufactured under a ISO 9001 registered quality system
- Runs on 3 AA alkaline professional batteries providing up to 1,500 hours of service
Pressure is Our Business!
|
|
Your ATEX Compact Vacuum Meter for 1050 to 1 mbar
The compact vacuum meter VD82 is fully electronic and combine high quality sensors and modern microcontroller technology with a handy design.
Our customers appreciate these easy-to-operate gauges as reliable tools in plant engineering, service and laboratory.
The digital display of your vacuum meter shows the exact absolute pressure. Sensors with temperature compensation and sophisticated evaluation electronics guarantee precise and reproducible measurement results.
Further Advantages
- External sensor
- Display of minimum and maximum pressure
- Automatic switch-off or continuous operation
- High battery lifetime due to clocked measurement
- Operation with battery or mains adapter
- Robust stainless steel flange
- For mobile use or fixed installtion |
|
In the field of PRESSURE AEP transducers offers a new series of digital pressure gauges from 1 up to 2000 bar with precision classes varying from 0.05% up to 0.2%.
Inside the range there are two main families :
The manometers generally dedicated to the automation complete with set point with internal relay, analogue and digital output, remote functions like zero, peak and hold in order to be interfaced with more advanced systems like PC, PLC etc...
The first-line-sample manometers c/w internal batteries (1 year autonomy) and serial output, suitable for checking plants or other pressure gauger both in industrial processes and in the laboratories.
Some models are provided complete with SIT certificate to attest the high grade of precision and can be supplied with manual pressure industrial generator and software for the calibration of manometers, supplier of pressure transducers, professional transmitters and pressure switches manufacturers.
To better suit the different applications, the manometers can be programmed by adjusting the digital professional filter, the display resolution and the pressure measurement unit which in some models can be converted in a force unit to measure loads generated by hydraulic or air cylinders.
|
|
- Accuracy: ±1% of full scale
- LCD Display: 30X 14.5cm, with 4 digits
- Dimension: ø3", H11.5 X W4.5cm
- Operating Temperature: -40 to 150°C
- Over Pressure: 2* full scale
- Process Connections: ¼" NPT Male, standard
- Connection Material: SS316L |
|
Piezoresistive sensor element Accuracy 0,25 %, 0,1 % or 0,05 % F.S. Total Error Band includes all effects of linearity, hysteresis, repeatability and temperature from -18 up to 63 °C
Characteristics:
* Industry leading accuracy
* Big display with bar graph
* Rugged stainless steel case
* 12 Engineering units
* Min./max. recall
* 7 Languages
* Adjustable update and dampen modus
* Display backlight
* Field calibration capability
* Disable mode
Measuring range: -1 ... 0 bar up to 0 ... 500 bar
-30 ... 0 in. Hg up to 0 ... 7000 ps |
|
Professional digital displays, Meters, and Manometers: Setra's LCD digital professional displays can be used in-line or as an integral part of the pressure transducer or transmitter. The Datum 2000 manometer is a complete system, includes choice of Model 204, 204D or 239. In addition, Setra's Datum 2000 meter and manometer feature a user-friendly selectable menu.
Model LD330: The Model LD330 with Liquid Professional crystal Display (LCD), can be configured in line between Setra's pressure transducer (or transmitter) and a manufacturers of data acquisition system. Value is built in to the design with a rotatable housing for optimum display viewing at any angle.
Datum 2000: Dual Channel Meter or Manometer - The Datum 2000 Dual Channel Meter can be configured externally with one or two pressure transducers or industrial transmitters. The Datum 2000 Manometer is a fully self-contained unit with factory installed pressure transducer or transmitter.
|
|
The VEGABAR 50 is the new generation of pressure pick-ups VEGA. Thanks to technologies with layer DMS mines and ceramics-capacitive CERTEC, they covers the measurement brackets from -1 to 600 bar in pressure relative and from 0 to 25 bar in absolute pressure with a class of precision which can go until < 0,1%.
According to the criteria of your application, you have the choice between several references offering necessary qualities and performances to you: intrinsic safety, very high behavior with the overloads, membrane levelling, great measurement bracket or excellent behavior with abrasion.
Another outstanding innovation is incorporation directly in the sensor of a datalogger making it possible to record a history of measurement over one definite period.
This new family of sensor is of course integrated in the new concept plics® of VEGA. That means in particular various options of case (plastic, aluminum or stainless) and of the electronic alternatives analogical 4... 20mA/HART® or numerical (Fieldbus Foundation and Profibus Pa). These sensors lay out of approval ATEX for explosive atmospheres gas and dust.
The startup is simpler to realize, either using the module of programming and skewerable indication PLICSCOM with clear texts, or by PC using PACTware according to concept DTM/FDT.
|
|
ServiceJunior without professional yarn.
Little genius of the diagnosis
Description:
- Transmission without yarn of the data.
- Possibility of data acquisition on the long term.
- Digital display with lighting.
- Conceived for professional remote control.
- Kit containing the JuniorWin software for PC.
- Function selected of peak (posting with bars and function actuated needle).
- Measurement of the points of pressure at rate of 10 ms reading (function max. min/).
- Range 50 m minimum.
- Whole Posting of the scale.
- Simplicity of handling by 4 keys.
- Integrated Battery: lifespan 1.500 hours.
- Index of protector IP54.
- Beach of pressure: -1... 16 bar/0... 100 bar/0... 400 bar/0... 600 bar.
Advantages:
- "Intelligent" Management of the memory.
- Is based on technology without wire, no connection by cable towards the PC is not necessary.
- A faster transfer of the data Allows the PC.
- Direct and simple Connection of ServiceJunior on the hydraulic system.
- No other portable apparatus nor another sensor and cable are necessary.
- Simple Use with lower costs for better results.
- Robust Enclosure not dirtying.
Applications:
- Equipment tools
- Mobile Machines
|
|
