ABUS Electric Chain Hoists are available for a safe working load up to 4 tonnes and feature user friendly advantages such as:
Extreme low headroom, dual speed lifting as standard, brake linings with exceptionally long lasting wear characteristics as well as a large variety of additional features.
|
|
|
The DC-Pro chain hoist for loads up to 5,000 kg is a fully featured, highly versatile chain hoist, which can be installed and put into service in a minimum of time. It is extremely user- and maintenance-friendly and features an ergonomic design with a high standard of safety and reliability. The particularly long service life (FEM 2m+) provides even greater operating efficiency.
|
|
With suspension hook. push, geared or electric trolley.
Standard lift height 3 m, control cable 2.5m
Operating voltage 220-440V, 50/60Hz, 1-3 phase
Low voltage control 36V is standard.
High efficient energy-saving motor, asbestos free brake system.
Light weight, compact and solid body case.
Top and bottom hooks are fitted with safety latches as standard.
Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.
Solid chain bucket.
Super strong surface hardened chain
Limit switch devices fitted at both top & bottom ends, switch off power automatically to prevent load chain from running out.
Phase error relay, a specially designed current-post, prevents motor from running at incorrect wire connection.
Overload protection and thermal protection.
|
|
Demag DCM-Pro Manulift:
The DCM-Pro Manulift was developed for handling loads quickly and safely with only one hand. The new DCM-Pro is based on the lifting unit of the DC-Pro chain hoist and the DSM-C control unit which is connected to it by a helical cable. Thanks to the control unit which is rigidly connected to the load handling attachment for right and left-handed operation, the operator only needs one hand to operate the chain hoist and guide the load.
|
|
3 ranges: electric hoist CPS, capacities of 125 kg to 500 kg, casing aluminum, thermal protection,...
Electric hoist PVC, capacities from 500 to 2000 kg, 1 or 2 speeds of lift, groups FEM 1Am, hour meter and of startings, end of the road high and low electric,...
Electric hoist CPE, capacities from 1.6 to 10 T, 2 speeds, engine designed for high duty ratios.
|
|
|
|
|
|
The DMK electric chain hoists respond to the needs of the international markets which require products of guaranteed quality with a wide range of uses, long-term reliability, safety guarantees in all phases of operation, and excellent value for money. The DMK hoists stand out for their careful and modern design putting them a the top of their category. The quality of the components, the high technology used in the production of the mechanical parts, in the finishes and in the surface treatments, the constant and checked quality system UNI EN ISO 9001 which covers the company's entire production, allow Donati Sollevamenti to offer a product in line with the latest international standards.
The special water-repellent paintwork is applied with an electrostatic process in complete isolation which guarantees its durability and a constant high performance, also in particularly hostile environments.
The DMK electric chain hoists are part of the lifting products range manufactured by Donati Sollevamenti, a leading company in its filed in Italy, and one of the leading companies in the world in the lifting equipment sector. The warranty lasts 3 years from the delivery date.
|
|
|
|
|
|
Housing
- Cast aluminium housing with maximum solidity (no plastic material)
- For extreme working conditions: casted cooling gills
Motor
- Design for tough working conditions
- Normal, fast and super fast speed models available
Transmission
- Helical-toothed first and second gear step for quiet running
- Permanent lubrication for wear resistant operation
Brake
- Maximum safety (construction: brake after slipping clutch)
- New advanced brake design
Slipping clutch
- Simple and precise adjustment
- Maintenance free and highly resistant to wear
Chain guidance
- 2-part construction to optimize maintenance
- Reinforced plastic material highly wear resistant
Chain wheel
- Made of hardened steel
- With additional chain pockets (4 mm): hence quiet running
Hoisting chain
- Zinc plated
- Surface-hardened
Geared limit switch (standard)
- Simple adjustment
- Exact positioning
Contactor control system
- Simple technology (no electronics susceptible to interference)
- 42 V control system allowing highest safety of operation
Control switch
- With built-in support wire as a standard
- 2-buttons: design especially ergonomic
|
|
|
Shh serie electric chain hoist have newest square shape complied with the international demand. the high intension aluminium alloy outline cover in very beautiful,light construction,strong corrosio resistance,which suitable for the high classification working.the distance between hooks invery small. unique friction clutch overload protection, which can protect the machine when overloading and overwinding. the column rotor taper breakong motor with dish reliable,low yawp,long using life.the bidirectional lifting limited confirm use safety.the carbonized load chain with high tension and abrasive resistance.high quality electric control component with low malfunction and high safety protection,new construction,modularze designing etc., which can assemble multiform with one economy,It's very convenient for repair and tear open.theproduct is complied with the up to date international standard.
|
|
|
ACI's single-phase electric chain hoists are among the most dependable on the market. The MH series was designed for heavy duty applications, which greatly reduces down time and operational costs. Ideal for mechanics and other shop applications, where lightweight hoists and portability count. Operates on standard 110-120V AC, which means you can plug it in just about anywhere! The long fifteen foot power cord plugs into any standard outlet. No three-phase hook-up necessary! ACI chain hoists tolerate large loads with ease and require little maintenance. May be purchased on its own or bundled with a heavy-duty push trolley.
|
|
There are two main types of electric hoists:
Chain hoists...
- lift by pulling the chain through sprockets and depositing the chain into a chain container
- are more common for applications below 7.5 tons
- require less maintenance
- are less expensive
- provide true vertical lift at no extra cost
Wire rope hoists...
- lift by wrapping cable around a grooved drum
- dominate the market at 10 tons and above
- offer very fast lifting speeds
- offer a wide array of options
- can be rated H-5 (severe duty)
Both chain and wire rope hoists are rated H-4 (heavy duty) or H-3 (moderate duty). Duty ratings are a better indicator of hoist durability than hoist type (chain or wire rope). Both types use similar motors, brakes and controls. The main difference between electric chain hoists and wire rope hoists is in the design of the lifting mechanism.
Be sure to request an H-4 rating on either your chain or wire rope hoist to ensure long life and low maintenance.
|
|
Electric chain hoists
A complete range of electric chain hoists
Five capacities from 125 to 2000 kg for many lifting and handling applications.
Features :
• Lightweight aluminium casing.
• Minimal lost height below the hook.
• Adjustable upper and lower end limit switches.
• Friction load limiter on all models
• Load chain to DIN 5684, class 8 case hardered.
• Operating factor : 30% to FEM 1 Am, ISO M4, tested to FEM n° 9511, 9755 and 9852.
• IP 55 protection.
• Low voltage controls (48V) : Télémécanique groupe SCHNEIDER electric components and pendant control box.
• CE marked (Machine Directive 89/392/CEE, 91/368/CEE, 93/44/CEE and 93/31/CEE, EMC Directive 89/336/CEE and 92/31/CEE).
• In accordance with standards N° EN 292-1 & -2, EN 418, EN 55014, EN 61000-2-3, EN 61000-3-3.
• Emergency stop on all models by main contactor in accordance with EN 418 category O.
|
|
|
|
|
|
Konecranes is one of the world's leading manufacturer of chain hoists and is dedicated to giving our customers advanced technology with the best value for money.
The XN chain hoist, ranging from 65 kg up to 7500 kg, is a compact, efficient electric chain hoist that combines safety with performance and high technology with modern design. The XN Chain Hoist provides cost-effective and reliable service for a variety of applications.
XN types:
- Hook suspended models for stationary lifting
- XM workstation crane trolley models
- Push trolley for manual travelling
- Motor trolleys for electrical trolley travel
Standard on the XN chain hoists:
- 2-speed hoisting motor for faster load positioning
- Friction torque limiter for maximal safety
- Built-in control panel with IP55 protection
- High tensile strength chain for long lifetime
- Slipping clutch/brake arrangement
Options:
- Upper and lower limit switches for increased safety
- Thermal protection of the hoisting motor
- Variable travelling speed control for increased productivity
- Thermal protection of the travelling motor
- Hour counter
and many more features to help you make the most of your electric chain hoist
|
|
Shophoist
Easy installation and maintenance
Standard protector overload device
10-pocket,oblique lay liftwheel for smooth chain operation, constant chain speed and reduced chain wear
NEMA 4, industrial-rated control station
Gear train lifetime lubricated with non-oxidizing grease
Alloy load chain for smooth operation and maximum chain life
Thermally-protected hoist duty motor
Dual brake system - D.C. plus regenerative
Rugged cast aluminum alloy hoist frame
Small, compact design for commercial applications
Totally enclosed, non-ventilated hoist frame protects the motor from environmental contamination
Optional impact-resistant chain container is available
Rigid latch style upper hook prevents tangling of power cord
Precision bearings used throughout the hoist
Hardened forged steel latch-style lower hook rotates 360:
True vertical lift
Lifetime Warranty
|
|
|
In our SK series for loads between 125 and 5,000 kg, we have packed high-performance motors into a compact design. the extremly sturdy construction guarantees long service life, reliable operation and low maintenance and service costs. The drive systems with variable speed control reduce swaying and allows for the careful handling of the loads. Noise levels are reduced thanks to the smooth and silent running of the trolley.
|
|
AccoLift
Standard Features:
Dual Brake System :
Disc type motor brake working with a mechanical load
brake provides load lowering control. Electric brake
designed for easy access and simple adjustment.
Upper and Lower Limit Switch :
Prevents overwinding by stopping operation in the case of
overlifting or overlowering.
Overload Alert :
Installed as load detecting safety device to prevent
overload for greater hoist longevity.
Push Button Control :
Compact design to enable one-handed operation. Rated
NEMA 4 protection. Emergency stop button included.
Push button cable has strain relief to prevent cable
damage.¬«
|
|
The model CPS is the smallest and lightest within the family of Yale electric chain hoists. Reliability and compact design make it ideal for numerous applications in the construction industry, service companies and many industrial areas for moving small and medium loads.
Features
- Standard lift height 3 m, control cable 2 m (direct control)
- The 10-pocket load sheave ensures a smooth running of the chain and minimizes chain wear.
- Distance between hooks only 276 mm (up to 250 kg capacity)
|
|
GIS electric chain hoists
Quality products from own manufacturing series. Lifting capacity between 40 and 5000 kg. Standard top equipment with optimum safety devices such as contactor control 42 V, slipping clutch or limit switches for highest and lowest hook positions.
Benefits:
Maintenance
- reliable, also during extreme conditions
- easy to operate
- brake system practically maintenance free
- wear resistance of brake and clutch
Load capacity
- very high duty factor according to FEM ratings
- lifting heights up to 120 m or more
Construction
- well-balanced in every position
Motor
- very high duty factor and percentage operating factor without immediate overheating of the motor
Slipping clutch
- slipping clutch engineered against overload only
- maximum safety thanks to separate limit stops
Control system
- 42 V low voltage control on all models
- electrical limit switch for upper and lower hook positions as standard
|
|
|
|
|
|
Electric Motor Driven Trolley
- Capacities 1/4 to 3 Tons
- Adjustable to fit wide range of beam flange widths
- Forms and integral hoist and trolley combination
- NEMA-4 push button, cable with steel strain relief-standard
- Single and two-speed models
- Choose a wide range of options and accessories
Steel frame side plates extend beyond the wheels for end stop contacts. Side plates have tapped holes for collector bracket attachment. Optional safety drop stops and bumpers.
- Wheels are forged heat-treated steel with contour tread for use on American Standard I-beam or wide flange beams.
- Traverse motor is 30-minute rated, totally enclosed non-ventilated with class "F" insulation and TAS as standard.
- Traverse gearing is housed in a heavy duty right angle drive reducer with output pinion meshing with machine cut wheel gears.
- Trolley controls are housed in a NEMA 1 enclosed panel mounted on the trolley side for easy access. The controls include a reversing contractor, terminal strip and NEMA 4X pendant station with hoist and trolley push-button controls as standard.
|
|
GIS electric chain hoists
Quality products from own manufacturing series. Lifting capacity between 40 and 5000 kg. Standard top equipment with optimum safety devices such as contactor control 42 V, slipping clutch or limit switches for highest and lowest hook positions.
Benefits:
Maintenance
- reliable, also during extreme conditions
- easy to operate
- brake system practically maintenance free
- wear resistance of brake and clutch
Load capacity
- very high duty factor according to FEM ratings
- lifting heights up to 120 m or more
Construction
- well-balanced in every position
Motor
- very high duty factor and percentage operating factor without immediate overheating of the motor
Slipping clutch
- slipping clutch engineered against overload only
- maximum safety thanks to separate limit stops
Control system
- 42 V low voltage control on all models
- electrical limit switch for upper and lower hook positions as standard
|
|
Push and Hand-Geared Trolleys
Capacities 1/4 - 25 tons
- Heavy rolled steel side frames extend beyond the wheels providing superior strength and added protection for trackwheels
- Thick section steel clevis suspended from steel equalizer pin. Alloy steel axles and equalizer pins are heat treated for maximum strength and wear life.
- Trolley wheels are fully machined from alloy cast iron and hardened for high strength and long service life. Units 1/4 through 16 tons employ universal wheel treads for use on flat or tapered beam flanges. 25 ton model operates on American Standard I-beams with tapered flanges. For patented track, consult factory.
- Lifetime lubricated, precision ball bearings standard on units through 3 ton capacity. 4 ton trolleys and greater feature eight, sealed Timken, tapered roller bearings and grease fittings.
- On hand-geared models, a hand chain operated wheel turns a machined steel drive pinion, engaging the two geared wheels.
|
|
