| The DC-Pro chain hoist for loads up to 5,000 kg is a fully featured, highly versatile chain hoist, which can be installed and put into service in a minimum of time. It is extremely user- and maintenance-friendly and features an ergonomic design with a high standard of safety and reliability. The particularly long service life (FEM 2m+) provides even greater operating efficiency. |
|
Housing
- Cast aluminium housing with maximum solidity (no plastic material)
- For extreme working conditions: casted cooling gills
Motor
- Design for tough working conditions
- Normal, fast and super fast speed models available
Transmission
- Helical-toothed first and second gear step for quiet running
- Permanent lubrication for wear resistant operation
Brake
- Maximum safety (construction: brake after slipping clutch)
- New advanced brake design
Slipping clutch
- Simple and precise adjustment
- Maintenance free and highly resistant to wear
Chain guidance
- 2-part construction to optimize maintenance
- Reinforced plastic material highly wear resistant
Chain wheel
- Made of hardened steel
- With additional chain pockets (4 mm): hence quiet running
Hoisting chain
- Zinc plated
- Surface-hardened
Geared limit switch (standard)
- Simple adjustment
- Exact positioning
Contactor control system
- Simple technology (no electronics susceptible to interference)
- 42 V control system allowing highest safety of operation
Control switch
- With built-in support wire as a standard
- 2-buttons: design especially ergonomic
|
|
Verlinde has always been among the first companies to introduce new ideas for the innovation of hoisting units with a hook (more than 70 patents taken out in France and around the world).
The new Eurobloc VT electric wire rope hoist has been created within this avant-garde spirit, as it accounts for a total of 13 patents on its own. |
|
ABUS Electric Chain Hoists are available for a safe working load up to 4 tonnes and feature user friendly advantages such as:
Extreme low headroom, dual speed lifting as standard, brake linings with exceptionally long lasting wear characteristics as well as a large variety of additional features.
|
|
~ high H4 duty cycle, up to 1,000 pounds and 300 motor starts per hour
~ 10 pocket oblique lay liftwheel provides longer chain wear
~ NEMA 4 industrial rated control station
~ Gear train lifetime lubricated with non-oxidizing grease
~ CM Hoist Alloy Load Chain
~ Dual braking system - D.C. plus regenerative |
|
The DMK electric chain hoists respond to the needs of the international markets which require products of guaranteed quality with a wide range of uses, long-term reliability, safety guarantees in all phases of operation, and excellent value for money. The DMK hoists stand out for their careful and modern design putting them a the top of their category. The quality of the components, the high technology used in the production of the mechanical parts, in the finishes and in the surface treatments, the constant and checked quality system UNI EN ISO 9001 which covers the company's entire production, allow Donati Sollevamenti to offer a product in line with the latest international standards.
The special water-repellent paintwork is applied with an electrostatic process in complete isolation which guarantees its durability and a constant high performance, also in particularly hostile environments.
The DMK electric chain hoists are part of the lifting products range manufactured by Donati Sollevamenti, a leading company in its filed in Italy, and one of the leading companies in the world in the lifting equipment sector. The warranty lasts 3 years from the delivery date. |
|
| ACI's single-phase electric chain hoists are among the most dependable on the market. The MH series was designed for heavy duty applications, which greatly reduces down time and operational costs. Ideal for mechanics and other shop applications, where lightweight hoists and portability count. Operates on standard 110-120V AC, which means you can plug it in just about anywhere! The long fifteen foot power cord plugs into any standard outlet. No three-phase hook-up necessary! ACI chain hoists tolerate large loads with ease and require little maintenance. May be purchased on its own or bundled with a heavy-duty push trolley. |
|
Shophoist
Easy installation and maintenance
Standard protector overload device
10-pocket,oblique lay liftwheel for smooth chain operation, constant chain speed and reduced chain wear
NEMA 4, industrial-rated control station
Gear train lifetime lubricated with non-oxidizing grease
Alloy load chain for smooth operation and maximum chain life
Thermally-protected hoist duty motor
Dual brake system - D.C. plus regenerative
Rugged cast aluminum alloy hoist frame
Small, compact design for commercial applications
Totally enclosed, non-ventilated hoist frame protects the motor from environmental contamination
Optional impact-resistant chain container is available
Rigid latch style upper hook prevents tangling of power cord
Precision bearings used throughout the hoist
Hardened forged steel latch-style lower hook rotates 360:
True vertical lift
Lifetime Warranty |
|
Hitachi Electric Hoist has the following special features:
Helical gearing: Quiet operations /Long life brake unit /Electro-magnetic contactor.
Reverse phase inspecting relay /Power chain /Chain container /Lower hook.
Limiting switch (upper and lower )/ Auxiliary brake system /Plug-in cables.
Push button cable /Push button switch /Hitachi overload limiter.
|
|
| ABUS Wire Rope Hoists lift up to 100 t SWL and provide modern technology with the highest possible reliability levels. They offer very compact design, very easy maintenance and come with precision travel and precision lifting speeds as standard. |
|
- Hoists from 1 to 50 Tonne
Foot mounted,
Low headroom Monorail, Birail
- Overhead travelling crane kits
from 1 to 50 Tonne
Single girder, Double girder
- Crane end-carriagesfrom
1 to 50 Tonne |
|
~ High-torque, heavy duty hoist motor
~ Alloy aluminum gear case and cover
~ Hinged contol panel cover
~ Positive action mechanical load lowering control
~ Easily accessible rope anchor
~ Integrally welded mounting lugs |
|
Donati wire rope guarantees maximum safety in hoisting up to 40.000 kgs. The competence and experience in design and production, the quality of componetns used, the high tecnology employed in the production of mechanical parts, in the finish and in surface treatments as well as the certified quality system UNI EN ISO 9001:1994 which regulates all the company's activity, allow Donati Sollevamenti to offer a product in line with the most modern international regularity standards.
The DRH electric rope hoist ensures use in a wide range of situations, reliability over time and safety in all operative phases.
The special hydro-repellent finish, obtained by an electrostatic process, guarantees long life and consistency in performance even in particularly hostile environments.
The company offers a 3-year guarantee starting from the date of delivery, all at a reasonable price. |
|
The SpeedHoist electric rope winch is specially designed for fast load handling applications with loads weighing up to 160 kg.
It is used when it is not necessary to balance the load or no compressed air is available. |
|
3 ranges: electric hoist CPS, capacities of 125 kg to 500 kg, casing aluminum, thermal protection,...
Electric hoist CPM, capacities from 250 to 2000 kg, 1 or 2 speeds of lift, groups FEM 1Am, hour meter and of startings, end of the road high and low electric,...
Electric hoist CPE, capacities from 1.6 to 10 T, 2 speeds, engine designed for high duty ratios. |
|
| Shh serie electric chain hoist have newest square shape complied with the international demand. the high intension aluminium alloy outline cover in very beautiful,light construction,strong corrosio resistance,which suitable for the high classification working.the distance between hooks invery small. unique friction clutch overload protection, which can protect the machine when overloading and overwinding. the column rotor taper breakong motor with dish reliable,low yawp,long using life.the bidirectional lifting limited confirm use safety.the carbonized load chain with high tension and abrasive resistance.high quality electric control component with low malfunction and high safety protection,new construction,modularze designing etc., which can assemble multiform with one economy,It's very convenient for repair and tear open.theproduct is complied with the up to date international standard. |
|
Standard equipment
- 1 or 2 lifting speeds
- top hook on request
- mechanical overload protection
- IP 54 protection for motors
- F insulation for motors
- 48 V control device
- IP 65 push button pendant
- two speed or variable speed (frequency control) on request
- suitable for ambient temperature - 20° +40°
- thermal probes for two-speed motors
- screw of limit switch on lifting, over 1000 Kg capacity |
|
This new generation of chain hoist sets the standards
for lifting and material handling beyond the millennium
We understand the challenges our customers face in this rapidly changing world, where increased competitive pressure will mean only the most productive will prosper. Increasing the efficiency of load lifting and material handling will be critical to overall productivity and the CX chain hoist is designed to meet these future demands and provide greater benefits to the user.
In short, CX technology provides the highest levels of reliability and productivity plus lower maintenance costs. The result is an excellent price/performance ratio which is what we know our customers want.
The logical modular design concept encompasses a wide range of formats including eye suspension, push travel and powered travel. Load capacities up to 2t are available in various speeds and duty classifications. Standard models are available rated in U.S. tons or metric tonnes/kgs.
Careful consideration has been given to optimise performance in all the typical chain hoist and conveying applications including fixed hoists, jib cranes, monorails, light track sections, work station cranes, overhead cranes and underslung cranes.
CX is the smallest member of a successful family of STREET hoists with capacities from 0.25t to 200t. CX is the product of meticulous research and development using advanced design methods including the latest solid modelling CAD techniques. |
|
----SH series steel rope electric hoist have newest designing with quadrate outline, modularize construction, good unitized capability. The fundamental mode combine is very convenient and multiform.
-----The special drive composition method is very stationary which save the usual long transmission shaft.
----The reducer use planet speed @down drive which have high effective , low yawp , long using life.
----Unique column rotor, taper breaking wheel motor with low yawp , disk reliable.
-----With the advanced technology from overseas, the guide rope unit is very reliable and safety.
----High precision and super mechanical spin limiter.
High quality control electric component with low malfunction.
----The products from 400kg to 50t with fully series , which are complied with the up to date international and domestic speciality standard.
|
|
Standard Equipment
· 1 or 2 lifting speed
· electro-mechanical overload protection
· electronic safety device is also available
· up and down screw type limit switch
· efficient rope guide
· duty factors of motors: 60 (1 speed) and 40/20 (2 speeds)
· lifting motors equipped with thermo probes
· IP 55 protection for motors and electrical controls
· F insulation for motors
· Load hook with latch
· two speed or variable speed (frequency converter) on request
· suitable for ambient temperature - 20° +40°. |
|
VX open winch hoists are designed to operate in tough, arduous conditions with high frequency of switching operations.
They can be rated for higher duty classifications and/or faster lifting speeds or with greater lifting heights than competitor hoists and the open plan design makes servicing and maintenance uniquely easy.
True vertical lift is standard, ensuring no deviation in the hook path throughout the full hook stroke.
VX open winch hoists are available in many formats with multiple combinations of drum length, gear ratio and rope reeve providing mechanical handling solutions up to 200t safe working load.
The most economic solutions are the standard formats however the flexible design is ideal for incorporating supplementary equipment and providing process integration to the most exacting specifications.
A wide range of duty classifications are available in accordance with European and US standards. Hoist and travel motors are available as dual speed or variable frequency control with electrical braking.
Modern design technology is combined with the robust construction necessary for reliable heavy lifting in the most arduous industrial applications. The Street VX hoist has achieved classic status for high productivity high performance and high precision. |
|
Demag DCM-Pro Manulift:
The DCM-Pro Manulift was developed for handling loads quickly and safely with only one hand. The new DCM-Pro is based on the lifting unit of the DC-Pro chain hoist and the DSM-C control unit which is connected to it by a helical cable. Thanks to the control unit which is rigidly connected to the load handling attachment for right and left-handed operation, the operator only needs one hand to operate the chain hoist and guide the load. |
|
GIS electric chain hoists
Quality products from own manufacturing series. Lifting capacity between 40 and 5000 kg. Standard top equipment with optimum safety devices such as contactor control 42 V, slipping clutch or limit switches for highest and lowest hook positions.
Benefits:
Maintenance
- reliable, also during extreme conditions
- easy to operate
- brake system practically maintenance free
- wear resistance of brake and clutch
Load capacity
- very high duty factor according to FEM ratings
- lifting heights up to 120 m or more
Construction
- well-balanced in every position
Motor
- very high duty factor and percentage operating factor without immediate overheating of the motor
Slipping clutch
- slipping clutch engineered against overload only
- maximum safety thanks to separate limit stops
Control system
- 42 V low voltage control on all models
- electrical limit switch for upper and lower hook positions as standard
|
|
GIS electric chain hoists
Quality products from own manufacturing series. Lifting capacity between 40 and 5000 kg. Standard top equipment with optimum safety devices such as contactor control 42 V, slipping clutch or limit switches for highest and lowest hook positions.
Benefits:
Maintenance
- reliable, also during extreme conditions
- easy to operate
- brake system practically maintenance free
- wear resistance of brake and clutch
Load capacity
- very high duty factor according to FEM ratings
- lifting heights up to 120 m or more
Construction
- well-balanced in every position
Motor
- very high duty factor and percentage operating factor without immediate overheating of the motor
Slipping clutch
- slipping clutch engineered against overload only
- maximum safety thanks to separate limit stops
Control system
- 42 V low voltage control on all models
- electrical limit switch for upper and lower hook positions as standard
|
|
