Description:
The Becker QTCV-T1 Quiet Trim Control Valve is a trunnion-mounted rotary control valve designed for general control valve service. The QTCV-T1 features a rugged design that provides moderate noise attenuating capabilities with extended an turndown ratio. The QTCV-T1 features a side-entry, forged body and end closures that allows easy maintenance or repair of the control valve. The QTCV-T1 is ideal for use as a flow control valve or pressure control valve where predicted noise does not pose a problem. The QTCV-T1 is available in a variety of configurations from 4" (100 mm) bore to 36" bore (900 mm).
|
|
CONSTRUCTION
Reduced bore, one piece body, floating ball, high performance low emission double stuffing box, relief seats, anti-static device, fire safe, pressure balance hole in ball, blow-out proof stem.
CHARACTERISTICS
High performance, low emission double stuffing box.
Internal wetted parts are acc. NACE Standard MR0175.
|
|
Series 040/050 - DN06 to DN50 PNO-16
Available with DVGW registration stampings
Fields of application :gas
|
|
The VENUS ball valve, with full bore, guarantees a high working reliability at low pressure in gas installations: is certified DIN DVGW by the German gas institute, and BRITISH GAS by the British gas institute.
Blow-out proof system, with perfect air bubble sealing, does not need any maintenance. The patented outside sealing system guarantees the maximum reliability during the time.
1 O-Ring in NBR for sealing at low pressure and vacuum.
All valves are tested at 25 bar pressure, for a period longer than 48 hours.
|
|
Description:
The Becker FPCV-T0 Full Port Control Valve is a trunnion-mounted rotary control valve designed for monitoring or mild-duty service above ground and heavy duty service below grade. The FPCV-T0 features a rugged design that provides maximum capacity with minimal full-open pressure drop. The FPCV-T0 features a side-entry, forged body and end closures that allows easy maintenance or repair of the control valve. The FPCV-T0 is ideal for use as a monitor over-pressure regulator or other mild-duty service. The FPCV-T0 is available in a variety of configurations from 2” (50 mm) bore to 42” bore (1050 mm).
|
|
APPLICATION:
To control the flow of Water, Air, Gas, Solvents, Vacuum and any other fluids not reactive with construction materials and free of sediment. Buna N seating of the main orifice make the valves ideal for TIGHT SEATING, LOW PRESSURE and LOW FLOW conditions. Valve operates from zero to maximum differential pressure indicated in table. Valve must be mounted in horizontal pipe with solenoid enclosure vertical and on top.
OPERATION:
Valve opens when energized and closes when de-energized. In this direct acting valve the disc holder assembly is lifted from its seat by the plunger.
|
|
APPLICATION:
To control the flow of Water, Oil, Air, Gas, Solvents, Brine, Vacuum and any other fluids not reactive with construction materials and free of sediment. Valve operates from zero to maximum differential pressure indicated in table. Valve must be mounted in horizontal pipe with solenoid enclosure vertical and on top.
OPERATION:
Valve opens when energized and closes when de-energized. When the coil is energized the pilot valve opens, relieving the pressure above the piston, which is then lifted from its seat by the plunger. Upon de-energizing the coil, a spring closes the pilot valve and opens a bleed passageway to permit pressure to build above the piston and seat it.
|
|
|
|
|
|
The Magna Flow Control Valve with an easy to read micrometer dial offers an amazing 1100 precise set points to accurately control flow of gases or liquids. The extremely high CV of the Magna Flow control valve enables very high flows for whatever media is being controlled, up to 200 PSIG pressure or full vacuum. Linear flow characteristics provide easy to set and precise metering of gases and liquids for almost any application where accurate results are required.
Available in either light weight impact resistant nylon or clear polycarbonate construction, the Magna Flow Control Valve offers superior strength and corrosion resistance, making it ideal for use in hundreds of different applications. Simplicity of construction, with removable top and bottom caps, provides easy disassembly for cleaning or maintenance without removing the valve from service. Proven O-ring seals provide a positive zero tight shut-off. Replacement of seals, if required, is quick and easy because disassembly is simple and fast. The Magna Flow Control Valve offers all these features at a very affordable price.
|
|
Description:
The Becker Series CVE & 41005 Globe Valve Regulator’s innovative design makes it among the most versatile natural gas contral valves in the world. Its cage-guided design utilizes multi-interchangeable trim styles, eliminating the need to change body styles. The Becker Globe valve is available with balanced or un-balanced trim for natural gas regulating applications such as pressure and flow control. Body styles provide a choice of flanged, buttweld, or threaded valve end connections.
|
|
|
|
|
|
Style 575 Angle Ball Valve
The Dresser® Style 575 Angle Ball Valve provides dual service... as a main-to-service compression end tee connection, and as a shut-off valve.
Constructed of a unique combination of a rugged ductile iron body and a highstrength engineered plastic plug, the "575" valve offers a low torque 90-degree operation with positive, bottle-tight shut-off at pressures up to 125 psi.
Designed for durability under all service conditions, the interface of ductile and engineered plastic components eliminates any possibility of valve freeze-up due to corrosion.
The "575" eliminates the presence of an isolated metallic valve in a plastic service. The ductile material in the valve body is compatible with the cast iron main, so there's no need for anoding and monitoring. Plus, an optional AL-CLAD® Plastisol coating can provide even greater external corrosion protection. The compression end for connecting the service is of a time-proven Dresser design and meets all the requirements of D.O.T. 192.283(b), providing a permanent seal and pull-out resistance greater than the PE tubing in tension.
The "575" is available in inlet sizes 1-1/4" or 1-1/2" MIPT and an outlet size of 1-1/8" OD, but it can be readily adapted to other outlet sizes as required.
|
|
These fuel shutoff valves are semi-automatic devices for shutdown of natural gas fueled engines. The valve is opened manually and closes when the electromagnet is energized and trips the latch.
The M2582 is a 1 inch (25 mm) valve with 1 NPT connections. It has one SPDT snap-switch. The valve body is made of sandcast aluminum. It does not include the open/close indicator button.
|
|
| ... products without technical information |
| |
CONSTRUCTION
Wafer body, double eccentric disc, adjustable stuffing box, The PTFE seat is energized by the Inconel metal seat, anti-static device, fire safe, blow-out proof stem.
CHARACTERISTICS
Internal wetted parts are in acc. to NACE Standard MR0175.
|
|
General description
Butterfly valves are the most efficient and reliable sealing Isolation valve mechanism under high vacuum working conditions. A vacuum seal provided around the plate periphery in the main body of the valve ensures fail proof working of the valve. For efficient working of the valve it is advised to ensure that the sealing plates are facing atmosphere.
Butterfly Valves are of small in terms of thickness which ensures easy and faster passage for air and gases and are ideally suited for "In-line" isolation purpose. Though the butterfly valve is not intended to be used as an independent valve, it is widely used as a Baffle Valve in union with a chevron baffle at the top of a Diffusion Pump. These Butterfly Valves are offered in stainless steel SS-304 non-magnetic AISI quality high carbon steel chromium plated construction and they can be manually or pneumatically operated as per customer choice.
|
|
| ... products without technical information |
| |
|
|
|
|
Weir SPM's Full Bore Unloading Valves provide over-pressure protection for pumps operating under a variety of pressures and flow conditions. The valves are compact, simple to operate, and rely on the system's pressure to open when a preset pressure is exceeded and automatically snaps shut when the pressure drops.
Features/Benefits
The valves are externally adjustable, and unlike shear relief valves which use common nails to trigger the valve, Weir SPM's Full Bore Unloading Valve utilizes nitrogen or rig air (properly filtered) to activate opening and closing. This model is available in 3" and 4" sizes. Operating pressures range from 5,000 psi to 20,000 psi. Standard service and sour gas models are available.
Remote Relief
Utilized together, the Full Bore Unloading Valve and Remote Control Panel increase safety for operators on drilling sites. Weir SPM designed a Remote Control Panel to work in conjunction with Weir SPM's Full Bore Unloading Valve (drilling applications) and the Emergency Backpressure Relief Valve (well service applications). The Remote Control Panel's primary function is to regulate the flow of air or nitrogen to the relief valve from a designated control station, allowing the operator to change the pressure relief settings with the turn of a knob at a safe distance.
|
|
Material according to EN161
Class: A
Group: 2
Media: gas
Pressure range : 0 to 4 bar max
Ambient temperature : -10° to +60° C max
Mounting : any position
Weight (including coil) : 280 g
Opening or closing time : 20 milliseconds maximum
|
|
|
The Alcon 2- way Gas & Fuel Oil Solenoid Valves are offered in 3 series of valves. The UGB Series has lightweight aluminum construction and is ideal for low-pressure natural gas. The U28 Series features a compact design that is ideal for air, inert gases, manufactured gas, natural gas, lp gas or light oil. All of these are approved safety shut-off valves. The UACF Series also features a compact design with Viton seal configuration providing approved safety shut-off for fuel oils.
|
|
T-GV Series normally open position
Application: natural gas lines, house, apartment, workhouse, workshop, factory,
it works with gas leak dedector alarm controller and earthquake alarm-controller.
Coil Voltage: 230, 220V, 110V, 24V, 12V AC, 24V, 12V DC
Gas Leak Controller: 230/220 V AC coil voltage
Earthquake Controller: 12 V DC coil voltage.
Protection Class: IP 65 with plug
Diaphragm: NBR
Way: 2/2 way, Normally Open position solenoid valve
Tube, Internal Parts: brass, stainless steel
|
|
SAFETY VALVES
This series of switch valves have been developed due to the safety level that Gas installations with Low, Average and High pressure require. Called SHUT %u2013 OFF, they get operational immediately when a electrical power %u2013 off is detected, making impossible to conect them automatically %u2013 requiring the oversight of a Technician. A review of the Gas System must be done and latter reassemble the valve.
They are made with an iron body with coiled or binded connection of 1" to 3", and pressures from 0 to 5 kg/cm2.
|
|
| ... products without technical information |
| |
Description:
The Becker Model VRP-B-CH Double-Acting Pilot provides pressure control when utilized with a double-acting piston actuated control valve. The VRP-B-CH measures process sensing pressure and positions the double-acting actuator to maintain the setpoint. The VRP-B-CH Pilot may be utilized for pressure control applications with setpoints ranging from 1.0 (6.9 kPa) to 1300 psig (8964 kPa). Due to its low-bleed characteristics, the VRP-B-CH is typically utilized when bleed gas must be discharged to atmosphere.
|
|
