The APS model is the perfect line to have a quick punching and cutting activities for profiles from 30x30 to 160x160x19 mm equipped by:
- A strong main body welded.
- Feeding system equipped by rollers driven by Brushless motor
- Separate Encoder for the feeding lenght management
- N. 2 punching units of 80 Tons, with axes driven.
- N. 1 cutting unit for profiles
- With standard equipment you can fit punches and dies from 5 mm up to 32 mm.
- Feeding units 6 meters
- CNC system for axes X, Y e Z management and punching cutting activities
- Pieces counter
- Set up for a different length, holes numbers and coordinates
- Programs archive
- Display Diagnostic System
- Hydraulic control unit complete with oil.
- CE certificate of conformity
SOFTWARE:
The APS is equipped with the latest generation of software. The program can work with the pieces saved in a data base and also enables designs of several pieces in one, nesting different parts in a sequence optimising the smallest amount of wasted material.
A DXF or DSTV converter is also available as option having the possibility to import and convert these files.
|
|
1. Adopt three-points rollers guide, through the force to the front roller by the papilionaceous spring, the cutting beam keeps in touch tightly with the two back rollers.
2. The special worktable structure designed from limit-element optimization make the curving Sx, which is formed during shearing, to be able to compensate the curving of upper beam under the acting of shearing force, assuring the blade gap to keep same along the full length of worktable, enhancing the shearing precision and quality.
3. GS adopt the compact hydraulic system of B O S C H , advanced compact structure design, the system pressure control adopt electro-Hydraulic proportional valve, the system pressure in a whole working period can be controlled by programming to ensure a stable working performances.
PLEASE WRITE ALL ENQUIRIES ONLY IN ENGLISH!
|
|
1. CE certification
2. All steel welded construction
3. Adopt three-points rolls guide
4. Ball worktable
5. Front sheet support arms
6. High quality shear blades
7. Front finger guard, side guard
8. OMRON photoelectric rear safety guards
PLEASE WRITE ALL ENQUIRIES ONLY IN ENGLISH!
|
|
The C2006 has a motorised rear buffer and a numerical control unit for greater efficiency.
- Cyclical cutting control.
- Illuminated cutting area.
- Upper and lower cutters with 4 blades.
- Optical-electronic safety device.
- 190 mm cutting neck.
- Cut material output ramp.
- Three 1,000 mm support arms
|
|
The E-volution in the shearing process is defined by the innovative technology of the new generation of Safan shears: the SAFAN M-Shear and the SAFAN B-Shear. In these shears, the control technology has evolved from hydraulic to electronic. The drive of the cutting beam consists of a servo-electronic motor and a hydraulic pump.
This unique hybrid drive makes the shears more environmentally friendly, low-noise and energy efficient. Their programmable cutting beam starting position, a variety of automatic settings, Touch Screen control and other features give these shears unmatched efficiency.
The fully equipped SAFAN M-Shear is available in working lengths from 2 to 8 metres and capacities from 4 mm to 16 mm sheet thickness. The SAFAN B-Shear is a simpler basic version, produced in one standard model only, that features the same superior technology.
|
|
|
ERMAK CNCHVR angle adjustable hydraulic guillotine shears are strong and easy to use machines which are able to cut any type of sheet with the best quality and speed. Machines could be programmed easily with the use of dialog programs on CYBELEC control units. When the type, thickness and length of the sheet is entered to the controller, machine calculates and adjusts blade gap adjustment, backgauge distance, cutting length and cutting angle automatically. Cutting angle adjustment is done automatically according to sheet thickness, so during cutting thin sheets, the shortest stroke is used.
|
|
Hydraulic Guillotine Shears
For Small- or High-volume Production
HACO has over thirty years of experience in building hydraulic guillotine shears. This expertise guarantees that you get virtually indestructible high-quality machines of great efficiency. We have hydraulic guillotine shears able to handle up to 32 mm thick mild steel sheets. Our machines can cut sheets up to 10 meters long. HACO has the best tool for all your sheet metal cutting jobs.
The program consists out of :
- TS : economic guillotine shears: 06 and 12mm capacity
- HSL : production guillotine shears : 06 up to 16mm capacity
- PS : 'heavy duty' production shears : 06 up to 32 mm capacity
- SST : swing-beam guillotine shears : 04mm
|
|
- Universal stencil owner
- stamping machines from holes to 38 mm
- type- enterprise and adjustable stroke length
- center pressure lubrication
- machines with small maintenance requirement
- five work stations (Compact 40, four work stations)
|
|
|
|
|
|
Hydraulic Guillotine Shears
BuCut H
Well engineered BuCut design is examined all problems that occured during cutting process. BuCut hydraulic guillotine shears provide high quality sheet metal cutting process with safety specifications.
The solid design with strengthen welded frame, BuCut is equiped according to customer preference. In this case you can find out friendly, reliability, precision and low maintenance in BuCut hydraulic quillotine shears.
BuTek Machinery has been designing and manufacturing special purposes machine for international companies. This time we reperesent state-of-art machine series BuCut Hydraulic Guillotine Shears with years of experience in sheet metal forming technology
Automatic blade gap adjustment provides cutting in different thickness of sheet metal.
Ergonomic and solid design with strengthen frame, quiet and high performance hydraulic unit, over-load protection and maintenance-free, these provide maximum productivity.
The rolling balls on the work table provides facility in cutting different length of sheet metal.
Hydraulic hold downs start before cutting and after that backguage is moving back side. These protect any deformation in sheet metal.
Advantages of BuCut
Programming BuTech Controller,
Backguage with ball-screw,
The open design of the hand quard provides for cutting small sheet,
Electronic positioning control,
Quiet and powerful hydraulic system
Cutting line illumination,
Light quards,
Support with T-slot and measuring tape,
Hydraulic over-load control,
Emergency stops,
|
|
|
We design and manufacture a full line of shearing equipment, including conventional and CNC-controlled guillotine shears and a CNC production cell with automatic sheet feed.
|
|
The hydraulic shears of the HS series are the ideal machines for those customers who want to have the best possible quality-price ratio in the field of bar shearing.
These simple and sturdy machines can meet all the requirements of the medium/small forging shops.
|
|
CAPACITY RANGE
Shearing capacity : from 6 to 30 mm
Shearing length : from 3100 mm to 8100 mm
MAIN FEATURES
- Heavy-duty "variable rake" design with throat
- Welded all steel frame providing maximum rigidity and cutting accuracy
- Extra-deep (350 mm) side frame throat allowing continuous strip slitting
- Power backgauge on ballscrews
- Swing-up backgauge for shearing longer pieces than backgauge range limit
- Backgauge retract function
- Compact, low-maintenance hydraulic unit
- Hydraulic holddown system
- Hydraulic overload protection
- Centralised manual lubrication system
- Adjustable stroke length to increase number of strokes on shorter cuts
|
|
|
|
|
|
Ursviken Guillotine Shears
Ursviken's shears are one of the most well known hydraulic shears in the world. They are reliable production machines for plate thicknesses 8 to 25 mm and cutting lengths 3 to 6.5 m and are made for cutting heavy plate with relatively small cutting angles (adjustable between 0.5 to 5 degrees). They are also effective for cutting of thin plate.
Ursviken's shears are equipped as standard with openings in the frame to make it possible to cut plates longer than the nominal length of the machine. The hydraulic system is built up by modern block hydraulics with logic elements to enbale even and shock-free operation. Ursviken's shears are available in 16 models.
Ursviken Guillotine Shear - GSA
- Electro-hydraulic setting of the blade clearance
- Steplessly variable cutting angle
- Automatic limitation of the cutting length
- Reversible, divided shear blades
- Hydraulic synchronization of the cylinders
- Shadow light
Ursviken Guillotine Shear - GSB
Ursviken GSB is a powerful shear made for cutting of high tensile materials up to 2" thick and 25' length.
Ursviken Guillotine Shear - GSB is available in 15 models.
|
|
Series Q11 Shearing Machine
Performance
This machine uses single-side machinical srive of beautiful appearance simple constructon .easily operation ,safe and relialbe , it`s widely used in motor ,electrical ,automobile industries and all shops of other industries where ,sheet metal cuting is required.
|
|
Iron-cutting Shears
Wherever shears are mentioned around the world, the OMERA name is invariably mentioned: in 50 years of hard work we have succeeded in meeting the needs of countless clients, and the experience accumulated over the years has enabled us to offer the market a range of iron-cutting shears with renewed performance and components, more modern design, and more economical and safer to use.
|
|
Cross cutting sheat with adjustable head
High efficient cutting shear with adjustable angle
for optimum integration into production line.
compact size - to be used in defined spaces
|
|
THE HIGH PERFORMANCE SHEARS
GSII & GXII types are specifically dedicated from 0,5 to 12 mm thick sheets.they have common components such as the frame, hydraulics, the back gauge and numerical control. Though, the blade clearance and the cutting angle are set automatically on GXII.
|
|
GHL shears are compact solutions of easy operation for the cut of plates up to 4 mm thickness.
With a good standard configuration, where we can point out the swing-up back gauge controlled by a touch-and-go control Adiramatic 2011 and the possibility to adjust the cutting length, GHL are the right alternative for companies that are starting their activity.
The thin gauge support table is an important aid for high quality and accurate cut-off strips.
|
|
Turbo hydraulic guillotine shears 6
of 1500 mm to 4000 mm/thickness: 6 mm
- Barrier postpones safety
- Visualisaiton angle of cut
- Mirror crosses to the layout
- Visualization length of cut
- Walk/Arrêt groups Hydraulique
- Lighting line of cut
- Master switch cadenassable
- Obstinate Advance postpones electric
- Retreat obstinate postpones electric
- Angle of cut +
- Angle of cut -
- Emergency Stop
Options
- Retractable programmable Thrust 1 axis, 9 programs of 9 dimensions
- Rule of square before length 2 meters
- Extension support-sheet length 2 meters
- Hydraulic Adjustment of the play between blades
|
|
