Cable hydraulic cutter EK 40
for concrete rebarfor pipeshigh-strength

Cable hydraulic cutter - EK 40 - KEMROC Spezialmaschinen GmbH - for concrete rebar / for pipes / high-strength
Cable hydraulic cutter - EK 40 - KEMROC Spezialmaschinen GmbH - for concrete rebar / for pipes / high-strength
Add to favorites
Compare this product

Characteristics

Application domain
for cables, for concrete rebar, for pipes
Options
high-strength, high resistance

Description

Overview
  • The EK 40 chain cutter is a continuous cutting attachment for mid-size excavators (5–11 t) that provides precise, low-impact trenching using a patented cutting chain system.
  • It is intended for cutting soil, asphalt, concrete and soft to medium rock up to 30 MPa UCS, delivering controlled material removal with reduced vibration and noise compared with percussive breakers.


Main benefits
  • Cutting depth up to 1,300 mm
  • Cutting width: 500 mm
  • Lower vibration and noise for work near structures and in urban areas
  • High-torque performance for stable cutting in compact soils and cohesive rock
  • Suitable for utilities, roadside works and renovation projects


Key features and technical advantages
  • Patented continuous cutting chain replaces percussive methods to produce accurate trench geometry and uniform profiles
  • High torque to maintain cutting progress without stalling and to reduce tool wear
  • Wear-optimized chain and pick arrangement for even wear distribution and extended service life
  • Hydraulically optimized for compatibility with modern mid-size excavators


Main applications
  • Utility and infrastructure trenching (water, gas, electrical, fiber-optic)
  • Asphalt and concrete cutting for repair and replacement preparation
  • Selective excavation and renovation where precise material removal is required
  • Trenching in soft to medium rock up to 30 MPa UCS (e.g., limestone, claystone, compacted soils)


Technical specifications
  • Recommended excavator weight: 5 – 11 t
  • Rated power: 44 kW (60 hp)
  • Drum cutter length (A): 1,300 mm
  • Cutting width (B): 500 mm
  • Cutter drum diameter (C): 475 mm
  • Recommended rpm: 90 rpm
  • Recommended oil flow: 85 l/min
  • Max. oil flow: 115 l/min
  • Max. operating pressure: 400 bar
  • Torque at 380 bar: 4,800 Nm
  • Cutting force at 380 bar: 20 kN
  • Max. rock compressive strength: 30 MPa
  • Weight: 750 kg
  • Pick box: PH 20 Type
  • Number of picks in cutter drums: 52 pcs
  • Number of picks in the cutter chain: 49 pcs
  • Standard pick: 16/46/38/20 C (ER 16/46/38/20 C)
  • Standard hole pattern: LB10
  • Compatible rotation unit (KRM): KRM35
